Today, we are excited to announce an early release of Microsoft Web Template Studio, a cross-platform extension for Visual Studio Code that simplifies and accelerates creating new full-stack web applications. Web Template Studio addresses a top community ask from developer surveys and 1-1 conversations with developers: Make it easy to create a new cloud-based web app. Web Template Studio uses a dev-friendly wizard to generate your application and provide a ReadMe.md to give you step by step instructions to get up and developing in no time. Best of all, Web Template Studio is open source on GitHub.

Our philosophy is to help bootstrap your app with what you need but not do so much that you’re deleting code and breaking stuff. We also strive to introduce best patterns and practices. Web Template Studio is extremely early in development, but we feel this is a great time to show it to the community and get a broader set of feedback. Web Template Studio currently supports one full-stack app path with React and Node.js. We want to partner with the community to see what else is useful and should be added. We know there are many more frameworks, pages and features to be added and can’t stress enough this is a work in progress. If there is something you feel strongly about, please let us know. Of course, we’re always willing to accept PRs. We want to be sure we’re building the right thing.

Web Template Studio takes the learnings from its sister project, Windows Template Studio which does the same concept but for native UWP applications. While the two projects target different development environments and tech stacks, they share a lot of tech under the hood.

Installing our nightly build

It is extremely easy, just head over to Visual Studio Marketplace’s Web Template Studio page and click “install” . In addition, you’ll need Node and Yarn installed as well.

A Lap Around Windows Template Studio

We launch WebTS by simply using the shortcut and typing in Web Template Studio. Super simple. This will fire up the wizard and you’ll be able to start generating a project in no time.

Step 1: Project Name and Output path

You start with your project name and output path.

Step 2: Project Type

Once you have selected a project type, you need to select a framework. You can select from Code behind, MVVM Basic or the very popular MVVM Light.

Step 3: Frameworks

Next, which frameworks do you want to use for your frontend and backend? We currently support one framework for frontend: React.js and one framework for backend: Node.js as this is an extremely early release.

Step 4: Pages and Cloud Services

To accelerate app creation, we provide several app page templates that you can use to add common UI pages into your new app. The current page templates include: blank page, common layouts (e.g., master detail) and pages that implement common patterns (e.g., grid, list). Using the wizard, add as many of the pages as you need, providing a name for each one, and we’ll generate them for you. Lastly, you specify which Azure cloud services you want to use, and we’ll build out the framework for the services into your app including tagging ‘TODO’ items. Currently supported services cover storage (Azure Cosmos DB), and compute (Azure Functions). We’ll even work on getting these initially deployed for you as well!

Step 5: Summary and generate

Simple as reviewing what you selected, being sure you’re ok with the licenses you’ll be adopting with your choices, and then clicking “Generate”. If you have a service, we’ll help you deploy it

Step 6: Running your app

Click the “Open project in VSCode” link. You can open up your Readme.MD file for helpful tips / tricks and then to get the webserver up and running, for React/Node.JS, you just need to open the terminal then type “yarn install” then “yarn start” and you’re up and going! As you can see, the web application is a solid starting point. It pulls real data, allows you to quickly refactor so you can spend your time on more important tasks like your business logic.

Preview upcoming features

We have done most testing inside WebTS on the React framework with Node.JS, however we do experimental versions for Angular and will be adding in Vue shortly too! If you want to kick the tires, go to Settings in Code and enable the Preview Mode option.

Open source and built by Microsoft Garage Interns

Web Template Studio is completely open-source and available now on GitHub. We cannot stress enough that this project is community led. We would love for you to contribute to the project and would encourage you to read our contribution guidelines for next steps. A public roadmap is currently actively being worked on as we need more feedback from the community.

We’d also like to directly state we’re proud to be created by Microsoft Garage interns. The Garage internship is a unique program for talented students to work in groups of 6-8 on challenging engineering projects. The Garage drives three primary goals, collaboration, creativity, and experimentation. The team partnered with teams across Microsoft along with the community to build the project. It has gone through multiple iterations variations to where it is currently today. I can’t tell you how proud I am of the work Amr, Danish, Imho, Jimmy, Kai, Kelly, Sahil, and Trevor did and humbled by how everyone supported their idea.

What is even more exciting is we have the new Garage interns working on the project as well over the next few months! They just started this week and are already digging into the project and how they can improve.

Get Started Today

Web Template Studio nightly are available now. We have extremely easy to use instructions for installing the VS extension on our GitHub page. We would love to hear how your experiences are using it and the helpfulness of the project. You can reach Clint at @clintrutkas. What are you waiting for? Go and try it out for yourself now!

The post Announcing Microsoft Web Template Studio appeared first on Windows Developer Blog.

Sprint 151 finished rolling out to all organisations end of last week and you can check out all the cool features in the release notes. Here is just a snapshot of some of the features that you can start using today, as well as some of the key announcements that we made at Microsoft Build last week.

Azure Boards app from the GitHub Marketplace

The new Azure Boards app in the GitHub Marketplace streamlines the acquisition and configuration of Azure Boards for your GitHub repositories, allowing you to monitor and link code activity with work items. To get started, install the app from the GitHub Marketplace in your GitHub account or organization. Check out the announcement blog post here. You can also see the GitHub & Azure Boards documentation for more information.

Azure Pipelines app for Microsoft Teams

You can now easily monitor Azure Pipelines and approve releases in Teams. In addition, you can manage subscriptions for completed builds, releases, pending approvals and get notifications for these events in your Teams channels. To get started, install the Azure Pipelines app from the Microsoft Teams app store.

Microsoft Build announcements

• Signing into Azure DevOps using your GitHub credentials Azure
• Kubernetes integration for Azure Pipelines and Multi-stage YAML pipelines
• Pay-per-GB pricing and more Azure Artifacts updates
• A simpler way to buy Azure DevOps

These are just the tip of the iceberg, and there is plenty more that we’ve released in Sprint 151. Check out the full list of features for this sprint in the release notes.

The post What’s new in Azure DevOps Sprint 151 + Microsoft Build announcements appeared first on Azure DevOps Blog.

Back when we were getting ready to ship .NET Core 2.0, I wrote a blog post exploring some of the many performance improvements that had gone into it. I enjoyed putting it together so much and received such a positive response to the post that I did it again for .NET Core 2.1, a version for which performance was also a significant focus. With //build last week and .NET Core 3.0‘s release now on the horizon, I’m thrilled to have an opportunity to do it again.

.NET Core 3.0 has a ton to offer, from Windows Forms and WPF, to single-file executables, to async enumerables, to platform intrinsics, to HTTP/2, to fast JSON reading and writing, to assembly unloadability, to enhanced cryptography, and on and on and on… there is a wealth of new functionality to get excited about. For me, however, performance is the primary feature that makes me excited to go to work in the morning, and there’s a staggering amount of performance goodness in .NET Core 3.0.

In this post, we’ll take a tour through some of the many improvements, big and small, that have gone into the .NET Core runtime and core libraries in order to make your apps and services leaner and faster.

Setup

Benchmark.NET has become the preeminent tool for doing benchmarking of .NET libraries, and so as I did in my 2.1 post, I’ll use Benchmark.NET to demonstrate the improvements. Throughout the post, I’ll include the individual snippets of benchmarks that highlight the particular improvement being discussed. To be able to execute those benchmarks, you can use the following setup:

1. Ensure you have .NET Core 3.0 installed, as well as .NET Core 2.1 for comparison purposes.
2. Create a directory named BlogPostBenchmarks.
3. In that directory, run dotnet new console.
4. Replace the contents of BlogPostBenchmarks.csproj with the following:


   <Project Sdk="Microsoft.NET.Sdk">

     <PropertyGroup>
       <OutputType>Exe</OutputType>
       <AllowUnsafeBlocks>true</AllowUnsafeBlocks>
       <TargetFrameworks>netcoreapp2.1;netcoreapp3.0</TargetFrameworks>
     </PropertyGroup>

     <ItemGroup>
       <PackageReference Include="BenchmarkDotNet" Version="0.11.5" />
       <PackageReference Include="System.Drawing.Common" Version="4.5.0" />
       <PackageReference Include="System.IO.Pipelines" Version="4.5.0" />
       <PackageReference Include="System.Threading.Channels" Version="4.5.0" />
     </ItemGroup>

   </Project>

5. Replace the contents of Program.cs with the following:


   using BenchmarkDotNet.Attributes;
   using BenchmarkDotNet.Configs;
   using BenchmarkDotNet.Jobs;
   using BenchmarkDotNet.Running;
   using BenchmarkDotNet.Toolchains.CsProj;
   using Microsoft.Win32.SafeHandles;
   using System;
   using System.Buffers;
   using System.Collections;
   using System.Collections.Concurrent;
   using System.Collections.Generic;
   using System.Collections.Immutable;
   using System.Diagnostics;
   using System.Drawing;
   using System.Drawing.Drawing2D;
   using System.Globalization;
   using System.IO;
   using System.IO.Compression;
   using System.IO.Pipelines;
   using System.Linq;
   using System.Net;
   using System.Net.Http;
   using System.Net.NetworkInformation;
   using System.Net.Security;
   using System.Net.Sockets;
   using System.Runtime.CompilerServices;
   using System.Runtime.InteropServices;
   using System.Security.Authentication;
   using System.Security.Cryptography.X509Certificates;
   using System.Text;
   using System.Text.RegularExpressions;
   using System.Threading;
   using System.Threading.Channels;
   using System.Threading.Tasks;
   using System.Xml;

   [MemoryDiagnoser]
   public class Program
   {
       static void Main(string[] args) => BenchmarkSwitcher.FromTypes(new[] { typeof(Program) }).Run(args);

       // ... paste benchmark code here
   }

To execute a particular benchmark, unless otherwise noted, copy and paste the relevant code to replace the // ...above, and execute dotnet run -c Release -f netcoreapp2.1 --runtimes netcoreapp2.1 netcoreapp3.0 --filter "*Program*". This will compile and run the tests in release builds, on both .NET Core 2.1 and .NET Core 3.0, and print out the results for comparison in a table.

Caveats

A few caveats before we get started:

1. Any discussion involving microbenchmark results deserves a caveat that measurements can and do vary from machine to machine. I’ve tried to pick stable examples to share (and have run these tests on multiple machines in multiple configurations to help validate that), but don’t be too surprised if your numbers differ from the ones I’ve shown; hopefully, however, the magnitude of the improvements demonstrated carries through. All of the shown results are from a nightly Preview 6 build for .NET Core 3.0. Here’s my configuration, as summarized by Benchmark.NET, on my Windows configuration and on my Linux configuration:


   BenchmarkDotNet=v0.11.5, OS=Windows 10.0.17763.437 (1809/October2018Update/Redstone5)
   Intel Core i7-7660U CPU 2.50GHz (Kaby Lake), 1 CPU, 4 logical and 2 physical cores
   .NET Core SDK=3.0.100-preview6-011854
     [Host]     : .NET Core 2.1.9 (CoreCLR 4.6.27414.06, CoreFX 4.6.27415.01), 64bit RyuJIT
     Job-RODBZD : .NET Core 2.1.9 (CoreCLR 4.6.27414.06, CoreFX 4.6.27415.01), 64bit RyuJIT
     Job-TVOWAH : .NET Core 3.0.0-preview6-27712-03 (CoreCLR 3.0.19.26071, CoreFX 4.700.19.26005), 64bit RyuJIT

   BenchmarkDotNet=v0.11.5, OS=ubuntu 18.04
   Intel Xeon CPU E5-2673 v4 2.30GHz, 1 CPU, 4 logical and 2 physical cores
   .NET Core SDK=3.0.100-preview6-011877
     [Host]     : .NET Core 2.1.10 (CoreCLR 4.6.27514.02, CoreFX 4.6.27514.02), 64bit RyuJIT
     Job-SSHMNT : .NET Core 2.1.10 (CoreCLR 4.6.27514.02, CoreFX 4.6.27514.02), 64bit RyuJIT
     Job-CHXNFO : .NET Core 3.0.0-preview6-27713-12 (CoreCLR 3.0.19.26071, CoreFX 4.700.19.26307), 64bit RyuJIT

2. Unless otherwise mentioned, benchmarks were executed on Windows. In many cases, performance is equivalent between Windows and Unix, but in others, there can be non-trivial discrepancies between them, in particular in places where .NET relies on OS functionality, and the OS itself has different performance characteristics.
3. I mentioned posts on .NET Core 2.0 and .NET Core 2.1, but I didn’t mention .NET Core 2.2. .NET Core 2.2 was primarily focused on ASP.NET, and while there were terrific performance improvements at the ASP.NET layer in 2.2, the release was primarily focused on servicing for the runtime and core libraries, with most improvements post-2.1 skipping 2.2 and going into 3.0.

With that out of the way, let’s have some fun.

Span and Friends

One of the more notable features introduced in .NET Core 2.1 was Span<T>, along with its friends ReadOnlySpan<T>, Memory<T>, and ReadOnlyMemory<T>. The introduction of these new types came with hundreds of new methods for interacting with them, some on new types and some with overloaded functionality on existing types, as well as optimizations in the just-in-time compiler (JIT) for making working with them very efficient. The release also included some internal usage of Span<T> to make existing operations leaner and faster while still enjoying maintainable and safe code. In .NET Core 3.0, much additional work has gone into further improving all such aspects of these types: making the runtime better at generating code for them, increasing the use of them internally to help improve many other operations, and improving the various library utilities that interact with them to make consumption of these operations faster.

To work with a span, one first needs to get a span, and several PRs have made doing so faster. In particular, passing around a Memory<T> and then getting a Span<T> from it is a very common way of creating a span; this is, for example, how the various Stream.WriteAsync and ReadAsync methods work, accepting a {ReadOnly}Memory<T> (so that it can be stored on the heap) and then accessing its Span property once the actual bytes need to be read or written. PR dotnet/coreclr#20771 improved this by removing an argument validation branch (both for {ReadOnly}Memory<T>.Span and for {ReadOnly}Span<T>.Slice), and while removing a branch is a small thing, in span-heavy code (such as when doing formatting and parsing), small things done over and over and over again add up. More impactful, PR dotnet/coreclr#20386 plays tricks at the runtime level to safely eliminate some of the runtime checked casting and bit masking logic that had been used to enable {ReadOnly}Memory<T> to wrap various types, like string, T[], and MemoryManager<T>, providing a seamless veneer over all of them. The net result of these PRs is a nice speed-up when fishing a Span<T> out of a Memory<T>, which in turn improves all other operations that do so.

private ReadOnlyMemory<byte> _mem = new byte[1];

[Benchmark]
public ReadOnlySpan<byte> GetSpan() => _mem.Span;

Of course, once you get a span, you want to use it, and there a myriad of ways to use one, many of which have also been optimized further in .NET Core 3.0.

For example, just as with arrays, to pass the data from a span to native code via a P/Invoke, the data needs to be pinned (unless it’s already immovable, such as if the span were created to wrap some natively allocated memory not on the GC heap or if it were created for some data on the stack). To pin a span, the easiest way is to simply rely on the C# language’s support added in C# 7.3 that supports a pattern-based way to use any type with the fixed keyword. All a type need do is expose a GetPinnableReference method (or extension method) that returns a ref T to the data stored in that instance, and that type can be used with fixed. {ReadOnly}Span<T> does exactly this. However, even though {ReadOnly}Span<T>.GetPinnableReference generally gets inlined, a call it makes internally to Unsafe.AsRef was getting blocked from inlining; PR dotnet/coreclr#18274 fixed this, enabling the whole operation to be inlined. Further, the aforementioned code was actually tweaked in PR dotnet/coreclr#20428 to eliminate one branch on the hot path. Both of these combine to result in a measurable boost when pinning a span:

private readonly byte[] _bytes = new byte[10_000];

[Benchmark(OperationsPerInvoke = 10_000)]
public unsafe int PinSpan()
{
    Span<byte> s = _bytes;
    int total = 0;

    for (int i = 0; i < s.Length; i++)
        fixed (byte* p = s) // equivalent to `fixed (byte* p = &s.GetPinnableReference())`
            total += *p;

    return total;
}

It’s worth noting, as well, that if you’re interested in these kinds of micro-optimizations, you might also want to avoid using the default pinning at all, at least on super hot paths. The {ReadOnly}Span<T>.GetPinnableReference method was designed to behave just like pinning of arrays and strings, where null or empty inputs result in a null pointer. This behavior requires an additional check to be performed to see whether the length of the span is zero:

// https://github.com/dotnet/coreclr/blob/52aff202cd382c233d903d432da06deffaa21868/src/System.Private.CoreLib/shared/System/Span.Fast.cs#L168-L174

[EditorBrowsable(EditorBrowsableState.Never)]
public unsafe ref T GetPinnableReference()
{
    // Ensure that the native code has just one forward branch that is predicted-not-taken.
    ref T ret = ref Unsafe.AsRef<T>(null);
    if (_length != 0) ret = ref _pointer.Value;
    return ref ret;
}

If in your code by construction you know that the span will not be empty, you can choose to instead use MemoryMarshal.GetReference, which performs the same operation but without the length check:

// https://github.com/dotnet/coreclr/blob/52aff202cd382c233d903d432da06deffaa21868/src/System.Private.CoreLib/shared/System/Runtime/InteropServices/MemoryMarshal.Fast.cs#L79

public static ref T GetReference<T>(Span<T> span) => ref span._pointer.Value;

Again, while a single check adds minor overhead, when executed over and over and over, that can add up:

private readonly byte[] _bytes = new byte[10_000];

[Benchmark(OperationsPerInvoke = 10_000, Baseline = true)]
public unsafe int PinSpan()
{
    Span<byte> s = _bytes;
    int total = 0;

    for (int i = 0; i < s.Length; i++)
        fixed (byte* p = s) // equivalent to `fixed (byte* p = &s.GetPinnableReference())`
            total += *p;

    return total;
}

[Benchmark(OperationsPerInvoke = 10_000)]
public unsafe int PinSpanExplicit()
{
    Span<byte> s = _bytes;
    int total = 0;

    for (int i = 0; i < s.Length; i++)
        fixed (byte* p = &MemoryMarshal.GetReference(s))
            total += *p;

    return total;
}

Of course, there are many other (and generally preferred) ways to operate over a span’s data than to use fixed. For example, it’s a bit surprising that until Span<T> came along, .NET didn’t have a built-in equivalent of memcmp, but nevertheless, Span<T>‘s SequenceEqual and SequenceCompareTo methods have become go-to methods for comparing in-memory data in .NET. In .NET Core 2.1, both SequenceEqual and SequenceCompareTo were optimized to utilize System.Numerics.Vector for vectorization, but the nature of SequenceEqual made it more amenable to best take advantage. In PR dotnet/coreclr#22127, @benaadams updated SequenceCompareTo to take advantage of the new hardware instrinsics APIs available in .NET Core 3.0 to specifically target AVX2 and SSE2, resulting in significant improvements when comparing both small and large spans. (For more information on hardware intrinsics in .NET Core 3.0, see platform-intrinsics.md and using-net-hardware-intrinsics-api-to-accelerate-machine-learning-scenarios.)

private byte[] _orig, _same, _differFirst, _differLast;

[Params(16, 256)]
public int Length { get; set; }

[GlobalSetup]
public void Setup()
{
    _orig = Enumerable.Range(0, Length).Select(i => (byte)i).ToArray();
    _same = (byte[])_orig.Clone();

    _differFirst = (byte[])_orig.Clone();
    _differFirst[0] = (byte)(_orig[0] + 1);

    _differLast = (byte[])_orig.Clone();
    _differLast[_differLast.Length - 1] = (byte)(_orig[_orig.Length - 1] + 1);
}

[Benchmark]
public int CompareSame() => _orig.AsSpan().SequenceCompareTo(_same);

[Benchmark]
public int CompareDifferFirst() => _orig.AsSpan().SequenceCompareTo(_differFirst);

[Benchmark]
public int CompareDifferLast() => _orig.AsSpan().SequenceCompareTo(_differLast);

As background, “vectorization” is an approach to parallelization that performs multiple operations as part of individual instructions on a single core. Some optimizing compilers can perform automatic vectorization, whereby the compiler analyzes loops to determine whether it can generate functionally equivalent code that would utilize such instructions to run faster. The .NET JIT compiler does not currently perform auto-vectorization, but it is possible to manually vectorize loops, and the options for doing so have significantly improved in .NET Core 3.0. Just as a simple example of what vectorization can look like, imagine having an array of bytes and wanting to search it for the first non-zero byte, returning the position of that byte. The simple solution is to just iterate through all of the bytes:

private byte[] _buffer = new byte[10_000].Concat(new byte[] { 42 }).ToArray();

[Benchmark(Baseline = true)]
public int LoopBytes()
{
    byte[] buffer = _buffer;
    for (int i = 0; i < buffer.Length; i++)
    {
        if (buffer[i] != 0)
            return i;
    }
    return -1;
}

That of course works functionally, and for very small arrays it’s fine. But for larger arrays, we end up doing significantly more work than is actually necessary. Consider instead in a 64-bit process re-interpreting the array of bytes as an array of longs, which Span<T> nicely supports. We then effectively compare 8 bytes at a time rather than 1 byte at a time, at the expense of added code complexity: once we find a non-zero long, we then need to look at each byte it contains to determine the position of the first non-zero one (though there are ways to improve that, too). Similarly, the array’s length may not evenly divide by 8, so we need to be able to handle the overflow.

[Benchmark]
public int LoopLongs()
{
    byte[] buffer = _buffer;
    int remainingStart = 0;

    if (IntPtr.Size == sizeof(long))
    {
        Span<long> longBuffer = MemoryMarshal.Cast<byte, long>(buffer);
        remainingStart = longBuffer.Length * sizeof(long);

        for (int i = 0; i < longBuffer.Length; i++)
        {
            if (longBuffer[i] != 0)
            {
                remainingStart = i * sizeof(long);
                break;
            }
        }
    }

    for (int i = remainingStart; i < buffer.Length; i++)
    {
        if (buffer[i] != 0)
            return i;
    }

    return -1;
}

For longer arrays, this yields really nice wins:

I’ve glossed over some details here, but it should convey the core idea. .NET includes additional mechanisms for vectorizing as well. In particular, the aforementioned System.Numerics.Vector type allows for a developer to write code using Vector and then have the JIT compiler translate that into the best instructions available on the current platform.

[Benchmark]
public int LoopVectors()
{
    byte[] buffer = _buffer;
    int remainingStart = 0;

	if (Vector.IsHardwareAccelerated)
	{
		while (remainingStart <= buffer.Length - Vector<byte>.Count)
		{
			var vector = new Vector<byte>(buffer, remainingStart);
			if (!Vector.EqualsAll(vector, default))
			{
				break;
			}
			remainingStart += Vector<byte>.Count;
		}
	}

    for (int i = remainingStart; i < buffer.Length; i++)
    {
        if (buffer[i] != 0)
            return i;
    }

    return -1;
}

Further, .NET Core 3.0 includes new hardware intrinsics that allow a properly-motivated developer to eek out the best possible performance on supporting hardware, utilizing extensions like AVX or SSE that can compare well more than 8 bytes at a time. Many of the improvements in .NET Core 3.0 come from utilizing these techniques.

Back to examples, copying spans has also improved, thanks to PRs dotnet/coreclr#18006 from @benaadams and dotnet/coreclr#17889, in particular for relatively small spans…

private byte[] _from = new byte[] { 1, 2, 3, 4 };
private byte[] _to = new byte[4];

[Benchmark]
public void CopySpan() => _from.AsSpan().CopyTo(_to);

Searching is one of the most commonly performed operations in any program, and searches with spans are generally performed with IndexOf and its variants (e.g. IndexOfAny and Contains) In PR dotnet/coreclr#20738, @benaadams again utilized vectorization, this time to improve the performance of IndexOfAny when operating over bytes, a particularly common case in many networking-related scenarios (e.g. parsing bytes off the wire as part of an HTTP stack). You can see the effects of this in the following microbenchmark:

private byte[] _arr = Encoding.UTF8.GetBytes("This is a test to see improvements to IndexOfAny.  How'd they work?");
[Benchmark] public int IndexOf() => new Span<byte>(_arr).IndexOfAny((byte)'.', (byte)'?');

I love these kinds of improvements, because they’re low-enough in the stack that they end up having multiplicative effects across so much code. The above change only affected byte, but subsequent PRs were submitted to cover char as well, and then PR dotnet/coreclr#20855 made a nice change that brought these same changes to other primitives of the same sizes. For example, we can recast the previous benchmark to use sbyte instead of byte, and as of that PR, a similar improvement applies:

private sbyte[] _arr = Encoding.UTF8.GetBytes("This is a test to see improvements to IndexOfAny.  How'd they work?").Select(b => (sbyte)b).ToArray();

[Benchmark]
public int IndexOf() => new Span<sbyte>(_arr).IndexOfAny((sbyte)'.', (sbyte)'?');

As another example, consider PR dotnet/coreclr#20275. That change similarly utilized vectorization to improve the performance of To{Upper/Lower}{Invariant}.

private string _src = "This is a source string that needs to be capitalized.";
private char[] _dst = new char[1024];
[Benchmark] public int ToUpperInvariant() => _src.AsSpan().ToUpperInvariant(_dst);

PR dotnet/coreclr#19959 optimizes the Trim{Start/End} helpers on ReadOnlySpan<char>, another very commonly-applied method, with equally exciting results (it’s hard to see with the white space in the results, but the results in the table go in order of the arguments in the Params attribute):

[Params("", " abcdefg ", "abcdefg")]
public string Data;

[Benchmark]
public ReadOnlySpan<char> Trim() => Data.AsSpan().Trim();

Sometimes optimizations are just about being smarter about code management. PR dotnet/coreclr#17890 removed an unnecessary layer of functions that were on many globalization-related code paths, and just removing those extra unnecessary method invocations results in measurable speed-ups when working with small spans, e.g.

[Benchmark]
public bool EndsWith() => "Hello world".AsSpan().EndsWith("world", StringComparison.OrdinalIgnoreCase);

Of course, one of the great things about span is that it is a reusable building-block that enables many higher-level operations. That includes operations on both arrays and strings…

Arrays and Strings

As a theme that’s emerged within .NET Core, wherever possible, new performance-focused functionality should not only be exposed for public use but also be used internally; after all, given the depth and breadth of functionality within .NET Core, if some performance-focused feature doesn’t meet the needs of .NET Core itself, there’s a reasonable chance it also won’t meet the public need. As such, internal usage of new features is a key benchmark as to whether the design is adequate, and in the process of evaluating such criteria, many additional code paths benefit, and these improvements have a multiplicative effect.

This isn’t just about new APIs. Many of the language features introduced in C# 7.2, 7.3, and 8.0 are influenced by the needs of .NET Core itself and have been used to improve things that we couldn’t reasonably improve before (other than dropping down to unsafe code, which we try to avoid when possible). For example, PR dotnet/coreclr#17891 speeds up Array.Reverse by taking advantage of the C# 7.2 ref locals feature and the 7.3 ref local reassignment feature. Using the new feature allows for the code to be expressed in a way that lets the JIT generate better code for the inner loop, and in turn results in a measurable speed-up:

private int[] _arr = Enumerable.Range(0, 256).ToArray();

[Benchmark]
public void Reverse() => Array.Reverse(_arr);

Another example for arrays, the Clear method improved in PR dotnet/coreclr#24302, which works around an alignment issue that results in the underlying memset used to implement the operation being up to 2x slower. The change manually clears up to a few bytes one by one, such that the pointer we then hand off to memset is properly aligned. If you got “lucky” previously and the array happened to be aligned, performance was fine, but if it wasn’t aligned, there was a non-trivial performance hit incurred. This benchmark simulates the unlucky case:

[GlobalSetup]
public void Setup()
{
    while (true)
    {
        var buffer = new byte[8192];
        GCHandle handle = GCHandle.Alloc(buffer, GCHandleType.Pinned);
        if (((long)handle.AddrOfPinnedObject()) % 32 != 0)
        {
            _handle = handle;
            _buffer = buffer;
            return;
        }
        handle.Free();
    }
}

[GlobalCleanup]
public void Cleanup() => _handle.Free();

private GCHandle _handle;
private byte[] _buffer;

[Benchmark] public void Clear() => Array.Clear(_buffer, 0, _buffer.Length);

That said, many of the improvements are in fact based on new APIs. Span is a great example of this. It was introduced in .NET Core 2.1, and the initial push was to get it to be usable and expose sufficient surface area to allow it to be used meaningfully. But at the same time, we started utilizing it internally in order to both vet the design and benefit from the improvements it enables. Some of this was done in .NET Core 2.1, but the effort continues in .NET Core 3.0. Arrays and strings are both prime candidates for such optimizations.

For example, many of the same vectorization optimizations applied to spans are similarly applied to arrays. PR dotnet/coreclr#21116 from @benaadams optimized Array.{Last}IndexOf for both bytes and chars, utilizing the same internal helpers that were written to enable spans, and to similar effect:

private char[] _arr = "This is a test to see improvements to IndexOf.  How'd they work?".ToCharArray();

[Benchmark]
public int IndexOf() => Array.IndexOf(_arr, '.');

And as with spans, thanks to PR dotnet/coreclr#24293 from @dschinde, these IndexOfoptimizations also now apply to other primitives of the same size.

private short[] _arr = "This is a test to see improvements to IndexOf.  How'd they work?".Select(c => (short)c).ToArray();

[Benchmark]
public int IndexOf() => Array.IndexOf(_arr, (short)'.');

Vectorization optimizations have been applied to strings, too. You can see the effect of PR dotnet/coreclr#21076 from @benaadams in this microbenchmark:

[Benchmark]
public int IndexOf() => "Let's see how fast we can find the period towards the end of this string.  Pretty fast?".IndexOf('.', StringComparison.Ordinal);

Also note in the above that the .NET Core 2.1 operation allocates (due to converting the search character into a string), whereas the .NET Core 3.0 implementation does not. That’s thanks to PR dotnet/coreclr#19788 from @benaadams.

There are of course pieces of functionality that are more unique to strings (albeit also applicable to new functionality exposed on spans), such as hash code computation with various string comparison methods. For example, PR dotnet/coreclr#20309/ improved the performance of String.GetHashCode when performing OrdinalIgnoreCase operations, which along with Ordinal (the default) represent the two most common modes.

[Benchmark]
public int GetHashCodeIgnoreCase() => "Some string".GetHashCode(StringComparison.OrdinalIgnoreCase);

OrdinalsIgnoreCase has been improved for other uses as well. For example, PR dotnet/coreclr#20734 improved String.Equals when using StringComparer.OrdinalIgnoreCaseby both vectorizing (checking two chars at a time instead of one) and removing branches from an inner loop:

[Benchmark]
public bool EqualsIC() => "Some string".Equals("sOME sTrinG", StringComparison.OrdinalIgnoreCase);

The previous cases are examples of functionality in String‘s implementation, but there are lots of ancillary string-related functionality that have seen improvements as well. For example, various operations on Char have been improved, such as Char.GetUnicodeCategory via PRs dotnet/coreclr#20983 and dotnet/coreclr#20864:

[Params('.', 'a', 'x05D0')]
public char Char { get; set; }

[Benchmark]
public UnicodeCategory GetCategory() => char.GetUnicodeCategory(Char);

Those PRs also highlight another case of benefiting from a language improvement. As of C# 7.3, the C# compiler is able to optimize properties of the form:

static ReadOnlySpan<byte> s_byteData => new byte[] { … /* constant bytes */ }

// Run with: dotnet run -c Release -f netcoreapp2.1 --filter *Program* --runtimes netcoreapp3.0

private static byte[] ArrayProp { get; } = new byte[] { 1, 2, 3 };

[Benchmark(Baseline = true)]
public ReadOnlySpan<byte> GetArrayProp() => ArrayProp;

private static ReadOnlySpan<byte> SpanProp => new byte[] { 1, 2, 3 };

[Benchmark]
public ReadOnlySpan<byte> GetSpanProp() => SpanProp;

Another string-related area that’s gotten some attention is StringBuilder (not necessarily improvements to StringBuilder itself, although it has received some of those, for example a new overload in PR dotnet/coreclr#20773 from @Wraith2 that helps avoid accidentally boxing and creating a string from a ReadOnlyMemory<char> appended to the builder). Rather, in many situations StringBuilders have been used for convenience but added cost, and with just a little work (and in some cases the new String.Create method introduced in .NET Core 2.1), we can eliminate that overhead, in both CPU usage and allocation. Here a few examples…

• PR dotnet/corefx#33598 removed a StringBuilder used in marshaling from Dns.GetHostEntry:

[Benchmark]
public IPHostEntry GetHostEntry() => Dns.GetHostEntry("34.206.253.53");

• PR dotnet/coreclr#21122 removed a StringBuilder used in Hebrew number formatting:

private static CultureInfo CreateCulture()
{
    var c = new CultureInfo("he-IL");
    c.DateTimeFormat.Calendar = new HebrewCalendar();
    return c;
}

private CultureInfo _hebrewIsrael = CreateCulture();

[Benchmark]
public string FormatHebrew() => new DateTime(2018, 11, 20).ToString(_hebrewIsrael);

• PR dotnet/corefx#33592 removed a StringBuilder used in PhysicalAddress formatting:

private readonly PhysicalAddress _short = new PhysicalAddress(new byte[1] { 42 });
private readonly PhysicalAddress _long = new PhysicalAddress(Enumerable.Range(0, 256).Select(i => (byte)i).ToArray());

[Benchmark]
public void PAShort() => _short.ToString();

[Benchmark]
public void PALong() => _long.ToString();

• PR dotnet/corefx#29605 removed StringBuilders from various properties of X509Certificate:

private X509Certificate2 _cert = GetCert();

private static X509Certificate2 GetCert()
{
    using (var client = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp))
    {
        client.Connect("microsoft.com", 443);
        using (var ssl = new SslStream(new NetworkStream(client)))
        {
            ssl.AuthenticateAsClient("microsoft.com", null, SslProtocols.None, false);
            return new X509Certificate2(ssl.RemoteCertificate);
        }
    }
}

[Benchmark]
public string CertProp() => _cert.Thumbprint;

and so on. These PRs demonstrate that good gains can be had simply by making small tweaks that make existing code paths cheaper, and that expands well beyond StringBuilder. There are lots of places within .NET Core, for example, where String.Substring is used, and many of those cases can be replaced with use of AsSpan and Slice, for example as was done in PR dotnet/corefx#29402 by @juliushardt, or PRs dotnet/coreclr#17916 and dotnet/corefx#29539, or as was done in PRs dotnet/corefx#29227 and dotnet/corefx#29721 to remove string allocations from FileSystemWatcher, delaying the creation of such strings until only when it was known they were absolutely necessary.

[Benchmark]
public void HtmlDecode() => WebUtility.HtmlDecode("水水水水水水水");

Another example of using new APIs to improve existing functionality is with String.Concat. .NET Core 3.0 has several new String.Concat overloads, ones that accept ReadOnlySpan<char> instead of string. These make it easy to avoid allocations/copies of substrings in cases where concatenating pieces of other strings: instead of using String.Concat with String.Substring, it’s used instead with String.AsSpan(...) or Slice. In fact, the PRs dotnet/coreclr#21766 and dotnet/corefx#34451 that implemented, exposed, and added tests for these new overloads also added tens of call sites to the new overloads across .NET Core. Here’s an example of the impact one of those has, improving the performance of accessing Uri.DnsSafeHost:

[Benchmark]
public string DnsSafeHost() => new Uri("http://[fe80::3]%1").DnsSafeHost;

Another example, using Path.ChangeExtension to change from one non-null extension to another:

[Benchmark]
public string ChangeExtension() => Path.ChangeExtension("filename.txt", ".dat");

Finally, a very closely related area is that of encoding. A bunch of improvements were made in .NET Core 3.0 around Encoding, both in general and for specific encodings, such as PR dotnet/coreclr#18263 that allowed an existing corner-case optimization to be applied for Encoding.Unicode.GetString in many more cases, or dotnet/coreclr#18487 that removed a bunch of unnecessary virtual indirections from various encoding implementations, or PR dotnet/coreclr#20768 that improved the performance of Encoding.Preamble by taking advantage of the same metadata-blob span support discussed earlier, or PRs dotnet/coreclr#21948 and dotnet/coreclr#23098 that overhauled and streamlined the implementions of UTF8Encoding and AsciiEncoding.

private byte[] _data = Encoding.ASCII.GetBytes("This is a test of ASCII encoding. It's faster now.");

[Benchmark]
public string ASCII() => Encoding.ASCII.GetString(_data);

These examples all served to highlight improvements made in and around strings. That’s all well and good, but where the improvements related to strings really start to shine is when looking at improvements around formatting and parsing.

Parsing/Formatting

Parsing and formatting are the lifeblood of any modern web app or service: take data off the wire, parse it, manipulate it, format it back out. As such, in .NET Core 2.1 along with bringing up Span<T>, we invested in the formatting and parsing of primitives, from Int32 to DateTime. Many of those changes can be read about in my previous blog posts, but one of the key factors in enabling those performance improvements was in moving a lot of native code to managed. That may be counter-intuitive, in that it’s “common knowledge” that C code is faster than C# code. However, in addition to the gap between them narrowing, having (mostly) safe C# code has made the code base easier to experiment in, so whereas we may have been skittish about tweaking the native implementations, the community-at-large has dived head first into optimizing these implementations wherever possible. That effort continues in full force in .NET Core 3.0, with some very nice rewards reaped.

Let’s start with core integer primitives. PR dotnet/coreclr#18897 added a variety of special paths for the parsing of Integer-style signed values (e.g. Int32 and Int64), PR dotnet/coreclr#18930 added similar support for unsigned (e.g. UInt32 and UInt64), and PR dotnet/coreclr#18952 did a similar pass for hex. On top of those, PR dotnet/coreclr#21365 layered in additional optimizations, for example utilizing those changes for primitives like byte, skipping unnecessary layers of functions, streamlining some calls to improve inlining, and further reducing branching. The net impact here are some significant improvements to the performance of parsing integer primitive types in this release.

[Benchmark]
public int ParseInt32Dec() => int.Parse("12345678");

[Benchmark]
public int ParseInt32Hex() => int.Parse("BC614E", NumberStyles.HexNumber);

Formatting of such types was also improved, even though it had already been improved significantly between .NET Core 2.0 and .NET Core 2.1. PR dotnet/coreclr#19551 tweaked the structure of the code to avoid needing to access the current culture number formatting data if it wouldn’t be needed (e.g. when formatting a value as hex, there’s no customization based on current culture), and PR dotnet/coreclr#18935 improved decimal formatting performance, in large part by optimizing how data is passed around (or not passed at all).

[Benchmark]
public string DecimalToString() => 12345.6789m.ToString();

In fact, System.Decimal itself has been overhauled in .NET Core 3.0, as of PR dotnet/coreclr#18948now with an entirely managed implementation, and with additional performance work in PRs like dotnet/coreclr#20305.

private decimal _a = 67891.2345m;
private decimal _b = 12345.6789m;

[Benchmark]
public decimal Add() => _a + _b;

[Benchmark]
public decimal Subtract() => _a - _b;

[Benchmark]
public decimal Multiply() => _a * _b;

[Benchmark]
public decimal Divide() => _a / _b;

[Benchmark]
public decimal Mod() => _a % _b;

[Benchmark]
public decimal Floor() => decimal.Floor(_a);

[Benchmark]
public decimal Round() => decimal.Round(_a);

Back to formatting and parsing, there are even some new formatting special-cases that might look silly at first, but that represent optimizations targeting real-world cases. In some sizeable web applications, we found that a large number of strings on the managed heap were simple integral values like “0” and “1”. And since the fastest code is code you don’t need to execute at all, why bother allocating and formatting these small numbers over and over when we can instead just cache and reuse the results (effectively our own string interning pool)? That’s what PR dotnet/coreclr#18383 does, creating a small, specialized cache of the strings for “0” through “9”, and any time we now find ourselves formatting a single-digit integer primitive, we instead just grab the relevant string from this cache.

private int _digit = 4;

[Benchmark]
public string SingleDigitToString() => _digit.ToString();

Enums have also seen sizable parsing and formatting improvements in .NET Core 3.0. PR dotnet/coreclr#21214 improved the handling of Enum.Parse and Enum.TryParse, for both the generic and non-generic variants. PR dotnet/coreclr#21254 improved the performance of ToString when dealing with [Flags] enums, and PR dotnet/coreclr#21284 further improved other ToString cases. The net effect of these changes is a sizeable improvement in Enum-related performance:

[Benchmark]
public DayOfWeek EnumParse() => Enum.Parse<DayOfWeek>("Thursday");

[Benchmark]
public string EnumToString() => NumberStyles.Integer.ToString();

In .NET Core 2.1, DateTime.TryFormat and ToString were optimized for the commonly-used “o” and “r” formats; in .NET Core 3.0, the parsing equivalents get a similar treatment. PR dotnet/coreclr#18800 significantly improves the performance of parsing DateTime{Offset}s formatted with the Roundtrip “o” format, and PR dotnet/coreclr#18771 does the same for the RFC1123 “r” format. For any serialization formats heavy in DateTimes, these improvements can make a substantial impact:

private string _r = DateTime.Now.ToString("r");
private string _o = DateTime.Now.ToString("o");

[Benchmark]
public DateTime ParseR() => DateTime.ParseExact(_r, "r", null);

[Benchmark]
public DateTime ParseO() => DateTime.ParseExact(_o, "o", null);

Tying back to the StringBuilder discussion from earlier, default DateTime formatting was also improved by PR dotnet/coreclr#22111, tweaking how DateTime internally interacts with a StringBuilder that’s used to build up the resulting state.

private DateTime _now = DateTime.Now;

[Benchmark]
public string DateTimeToString() => _now.ToString();

TimeSpan formatting was also significantly improved, via PR dotnet/coreclr#18990:

private TimeSpan _ts = new TimeSpan(3, 10, 2, 34, 567);

[Benchmark]
public string TimeSpanToString() => _ts.ToString();

Guid parsing also got in the perf-optimization game, with PR dotnet/coreclr#20183 improved parsing performance of Guid, primarily by avoiding overhead in helper routines, as well as by avoiding some searches used to determine which parsing routines to employ.

private string _guid = Guid.NewGuid().ToString("D");

[Benchmark]
public Guid ParseGuid() => Guid.ParseExact(_guid, "D");

Related, PR dotnet/coreclr#21336 again takes advantage of vectorization to improve Guid‘s construction and formatting to and from byte arrays and spans:

private Guid _guid = Guid.NewGuid();
private byte[] _buffer = new byte[16];

[Benchmark]
public void GuidToFromBytes()
{
    _guid.TryWriteBytes(_buffer);
    _guid = new Guid(_buffer);
}

Regular Expressions

Often related to parsing is the area of regular expressions. A bit of work was done on System.Text.RegularExpressions in .NET Core 3.0. PR dotnet/corefx#30474 replaced some usage of an internal StringBuilder cache with a ref struct-based builder that takes advantage of stack-allocated space and pooled buffers. And PR dotnet/corefx#30632 continued the effort by taking further advantage of spans. But the biggest improvement came in PR dotnet/corefx#32899 from @Alois-xx, which tweaks the code generated for a RegexOptions.Compiled Regex to avoid gratuitous thread-local accesses to look up the current culture. This is particularly impactful when also using RegexOptions.IgnoreCase. To see the impact, I found a complicated Regex that used both Compiled and IgnoreCase, and put it into a benchmark:

// Pattern and options copied from https://github.com/microsoft/referencesource/blob/aaca53b025f41ab638466b1efe569df314f689ea/System.ComponentModel.DataAnnotations/DataAnnotations/EmailAddressAttribute.cs#L54-L55
private Regex _regex = new Regex(
    @"^((([a-z]|d|[!#$%&'*+-/=?^_`{|}~]|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])+(.([a-z]|d|[!#$%&'*+-/=?^_`{|}~]|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])+)*)|((x22)((((x20|x09)*(x0dx0a))?(x20|x09)+)?(([x01-x08x0bx0cx0e-x1fx7f]|x21|[x23-x5b]|[x5d-x7e]|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])|(\([x01-x09x0bx0cx0d-x7f]|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF]))))*(((x20|x09)*(x0dx0a))?(x20|x09)+)?(x22)))@((([a-z]|d|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])|(([a-z]|d|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])([a-z]|d|-|.|_|~|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])*([a-z]|d|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF]))).)+(([a-z]|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])|(([a-z]|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])([a-z]|d|-|.|_|~|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF])*([a-z]|[u00A0-uD7FFuF900-uFDCFuFDF0-uFFEF]))).?$",
    RegexOptions.Compiled | RegexOptions.IgnoreCase | RegexOptions.ExplicitCapture);

[Benchmark]
public bool RegexCompiled() => _regex.IsMatch("someAddress@someCompany.com");

Threading

Threading is one of those things that’s ever-present and yet most apps and libraries don’t need to explicitly interact with most of the time. That makes it an area ripe for runtime performance improvements to drive down overhead as much as possible, so that user code just gets faster. Previous releases of .NET Core saw a lot of investment in this area, and .NET Core 3.0 continues the trend. This is another area where new APIs have been exposed and then also used in .NET Core itself for further gain.

For example, historically the only work item types that could be queued to the ThreadPool were ones implemented in the runtime, namely those created by ThreadPool.QueueUserWorkItem and friends, by Task, by Timer, and other such core types. But in .NET Core 3.0, the ThreadPool has an UnsafeQueueUserWorkItem overload that accepts the newly public IThreadPoolWorkItem interface. This interface is very simple, with a single method that just Executes work, and that means that any object that implements this interface can be queued directly to the thread pool. This is advanced; most code is just fine using the existing work item types. But this additional option affords a lot of flexibility, in particular in being able to implement the interface on a reusable object that can be queued over and over again to the pool. This is now used in a bunch of additional places in .NET Core 3.0.

One such place is in System.Threading.Channels. The Channels library introduced in .NET Core 2.1 already had a fairly low allocation profile, but there were still times it would allocate. For example, one of the options when creating a channel is whether continuations created by the library should run synchronously or asynchronously as part of a task completing (e.g. when a TryWrite call on a channel wakes up a corresponding ReadAsync, is the continuation from that ReadAsyncinvoked synchronously or queued by the TryWrite call). The default is that continuations are never invoked synchronously, but that also then requires allocating an object as part of queueing the continuation to the thread pool. With PR dotnet/corefx#33080, the reusable IValueTaskSource implementation that already backs the ValueTasks returned from ReadAsync calls also implements IThreadPoolWorkItem and can thus itself be queued, avoiding that allocation. This can have a measurable impact on throughput.

// Run with: dotnet run -c Release -f netcoreapp2.1 --filter *Program*

private sealed class Config : ManualConfig // also add [Config(typeof(Config))] to the Program class
{
    public Config()
    {
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp21).WithNuGet("System.Threading.Channels", "4.5.0").WithId("4.5.0"));
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp30).WithNuGet("System.Threading.Channels", "4.6.0-preview5.19224.8").WithId("4.6.0-preview5.19224.8"));
    }
}

private Channel<int> _channel1 = Channel.CreateUnbounded<int>();
private Channel<int> _channel2 = Channel.CreateUnbounded<int>();

[GlobalSetup]
public void Setup()
{
    Task.Run(async () =>
    {
        var reader = _channel1.Reader;
        var writer = _channel2.Writer;
        while (true)
        {
            writer.TryWrite(await reader.ReadAsync());
        }
    });
}

[Benchmark]
public async Task PingPong()
{
    var writer = _channel1.Writer;
    var reader = _channel2.Reader;
    for (int i = 0; i < 10_000; i++)
    {
        writer.TryWrite(i);
        await reader.ReadAsync();
    }
}

IThreadPoolWorkItem is now also utilized in other places, like in ConcurrentExclusiveSchedulerPair (a little known but useful type that provides an exclusive scheduler that limits execution to only one task at a time, a concurrent scheduler that limits a user-defined number of tasks to run at a time, and that coordinate with each other so that no concurrent tasks may run while an exclusive task is running, ala a reader-writer lock), which now implements IThreadPoolWorkItem on an internally reusable work item object such that it also can avoid allocations when queueing its own processors. It’s also used in ASP.NET Core, and is one of the reasons key ASP.NET benchmarks are ammortized to 0 allocations per request. But by far the most impactful new implementer is in the async/await infrastructure.

In .NET Core 2.1, the runtime’s support for async/await was overhauled, drastically reducing the overheads involved in async methods. Previously when an async method awaited for the first time an awaitable that wasn’t yet complete, the struct-based state machine for the async method would be boxed (literally a runtime box) to the heap. With .NET Core 2.1, we changed that to instead use a generic object that stores the struct as a field on it. This has a myriad of benefits, but one of these benefits is that it now enables us to implement additional interfaces on that object, such as implementing IThreadPoolWorkItem. PR dotnet/coreclr#20159 does exactly that, and it enables another large swath of scenarios to have further reduced allocations, in particular situations where TaskCreationOptions.RunContinuationsAsynchronously was used with a TaskCompletionSource<T>. This can be seen in a benchmark like the following.

// Run with: dotnet run -c Release -f netcoreapp2.1 --filter *Program*

private sealed class Config : ManualConfig // also add [Config(typeof(Config))] to the Program class
{
    public Config()
    {
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp21).WithNuGet("System.Threading.Channels", "4.5.0").WithId("4.5.0"));
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp30).WithNuGet("System.Threading.Channels", "4.6.0-preview5.19224.8").WithId("4.6.0-preview5.19224.8"));
    }
}

private Channel<TaskCompletionSource<bool>> _channel = Channel.CreateUnbounded<TaskCompletionSource<bool>>();

[GlobalSetup]
public void Setup()
{
    Task.Run(async () =>
    {
        var reader = _channel.Reader;
        while (true) (await reader.ReadAsync()).TrySetResult(true);
    });
}

[Benchmark]
public async Task AsyncAllocs()
{
    var writer = _channel.Writer;
    for (int i = 0; i < 1_000_000; i++)
    {
        var tcs = new TaskCompletionSource<bool>(TaskCreationOptions.RunContinuationsAsynchronously);
        writer.TryWrite(tcs);
        await tcs.Task;
    }
}

That change allowed subsequent optimizations, such as PR dotnet/coreclr#20186 using it to make await Task.Yield(); allocation-free:

[Benchmark]
public async Task Yield()
{
    for (int i = 0; i < 1_000_000; i++)
    {
        await Task.Yield();
    }
}

It’s even utilized further in Task itself. There’s an interesting race condition that has to be handled in awaitables: what happens if the awaited operation completes after the call to IsCompleted but before the call to OnCompleted? As a reminder, the code:

await something;

compiles down to code along the lines of:

var $awaiter = something.GetAwaiter();
if (!$awaiter.IsCompleted)
{
    _state = 42;
    AwaitOnCompleted(ref $awaiter);
    return;
}
Label42:
$awaiter.GetResult();

Once we go down the path of IsCompleted having returned false, we’re going to call AwaitOnCompleted and return. If the operation has completed by the time we call AwaitOnCompleted, we don’t want to synchronously invoke the continuation that re-enters this state machine, as we’ll be doing so further down the stack, and if that happened repeatedly, we’d “stack dive” and could end up overflowing the stack. Instead, we’re forced to queue the continuation. This case isn’t the common case, but it happens more often than you might expect, as it simply requires an operation that completes asynchronously very quickly (various networking operations often fall into this category). As of PR dotnet/coreclr#22373, the runtime now takes advantage of the async state machine box object implementing IThreadPoolWorkItem to avoid the allocations in this case as well!

In addition to IThreadPoolWorkItem being used with async/await to allow the async implementation to queue work items to the thread pool in a more allocation-friendly manner just as any other code can, changes were also made that give the ThreadPool 1st-hand knowledge of the state machine box in order to help it optimize additional cases. PR dotnet/coreclr#21159 from @benaadams teaches the ThreadPool to re-route some UnsafeQueueUserWorkItem(Action<object>, object, bool) calls to instead use UnsafeQueueUserWorkItem(IAsyncStateMachineBox, bool) under the covers, so that higher-level libraries can get these allocation benefits without having to be aware of the box machinery.

Another async-related area that’s seen measurable improvements are Timers. In .NET Core 2.1, some important improvements were made to System.Threading.Timers to help improve throughput and minimize contention for a common case where timers aren’t firing, but instead are quickly created and destroyed. And while those changes help a bit with the case when timers do actually fire, they didn’t help with the majority costs and sources of contention in that case, which is that potentially a lot of work (proportional to the number of timers registered) was done while holding locks. .NET Core 3.0 makes some big improvements here. PR dotnet/coreclr#20302 partitions the internal list of registered timers into two lists: one with timers that will soon fire and one with timers that won’t fire for a while. In most workloads that have a lot of registered timers, the majority of timers fall into the latter bucket at any given point in time, and this partitioning scheme enables the runtime to only consider the small bucket when firing timers most of the time. In doing so, it can significantly reduce the costs involved in firing timers, and as a result, also significantly reduce contention on the lock held while manipulating those lists. One customer who tried out these changes after having experienced issues due to tons of active timers had this to say about the impact:

“We got the change in production yesterday and the results are amazing, with 99% reduction in lock contention. We have also measured 4-5% CPU gains, and more importantly 0.15% improvement in reliability for our service (which is huge!).”

The nature of the scenario makes it a little difficult to see the impact in a Benchmark.NET benchmark, so we’ll do something a little different. Rather than measuring the thing that was actually changed, we’ll measure something else that’s indirectly impacted. In particular, these changes didn’t directly impact the performance of creating and destroying timers; in fact, one of the goals was to avoid doing so (in particular to avoid harming that important path). But by reducing the costs of firing timers, we reduce how long locks are held, which then also reduces the contention that the creating/destroying of timers faces. So, our benchmark creates a bunch of timers, ranging in when and how often they fire, and then we time how long it takes to create and destroy a bunch of additional timers.

private Timer[] _timers;

[GlobalSetup]
public void Setup()
{
    _timers = new Timer[1_000_000];
    for (int i = 0; i < _timers.Length; i++)
    {
        _timers[i] = new Timer(_ => { }, null, i, i);
    }
    Thread.Sleep(1000);
}

[Benchmark]
public void CreateDestroy()
{
    for (int i = 0; i < 1_000; i++)
    {
        new Timer(_ => { }, 0, 100, 100).Dispose();
    }
}

Timer improvements have also taken other forms. For example, PR dotnet/coreclr#22233 from @benaadams shrinks the allocation involved in Task.Delay when used without a CancellationToken by 24 bytes, and PR dotnet/coreclr#20509 reduces the timer-related allocations involved in creating timed CancellationTokenSources, which also has a nice effect on throughput:

[Benchmark]
public void CTSTimer()
{
    using (var cts = new CancellationTokenSource())
        cts.CancelAfter(1_000_000);
}

There are other even lower-level improvements that have gone into the release. For example, PR dotnet/coreclr#21328 from @benaadams improved Thread.CurrentThread by changing the implementation to store the relevant Thread in a [ThreadStatic] field rather than forcing CurrentThread to make an InternalCall into the native portions of the runtime.

[Benchmark]
public Thread CurrentThread() => Thread.CurrentThread;

As other examples, PR dotnet/coreclr#23747 taught the runtime to better respect Docker –cpu limits, PRs dotnet/coreclr#21722 and dotnet/coreclr#21586 improved spinning behavior when contention was encountered across a variety of synchronization sites, PR dotnet/coreclr#22686 improved performance of SemaphoreSlim when consumers of an instance were mixing both synchronous Waits and asynchronous WaitAsyncs, and PR dotnet/coreclr#18098 from @Quogu special-cased CancellationTokenSource created with a timeout of 0 to avoid Timer-related costs.

Collections

Moving on from threading, let’s explore some of the performance improvements that have gone into collections. Collections are so commonly used in pretty much every program that they’ve received a lot of performance-focused attention in previous .NET Core releases. Even so, there continues to be areas for improvement. Here are some example such improvements in .NET Core 3.0.

ConcurrentDictionary<TKey, TValue> has an IsEmpty property that states whether the dictionary is empty at that moment-in-time. In previous releases, it took all of the dictionary’s locks in order to get a proper moment-in-time answer. But as it turns out, those locks only need to be held if we think the collection might be empty: if we see anything in any of the dictionary’s internals buckets, the locks aren’t needed, as we’d stop looking at additional buckets anyway the moment we found one bucket to contain anything. Thus, PR dotnet/corefx#30098 from @drewnoakes added a fast path that first checks each bucket without the locks, in order to optimize for the common case where the dictionary isn’t empty (the impact on the case where the dictionary is empty is minimal).

private ConcurrentDictionary<int, int> _cd;

[GlobalSetup]
public void Setup()
{
    _cd = new ConcurrentDictionary<int, int>();
    _cd.TryAdd(1, 1);
}

[Benchmark] public bool IsEmpty() => _cd.IsEmpty;

ConcurrentDictionary wasn’t the only concurrent collection to get some attention. An improvement came to ConcurrentQueue<T> in dotnet/coreclr#18035, and it’s an interesting example in how performance optimization often is a trade-off between scenarios. In .NET Core 2.0, we overhauled the ConcurrentQueue implementation in a way that significantly improved throughput while also significantly reducing memory allocations, turning the ConcurrentQueue into a linked list of circular arrays. However, the change involved a concession: because of the producer/consumer nature of the arrays, if any operation needed to observe data in-place in a segment (rather than dequeueing it), the segment that was observed would be “frozen” for any further enqueues… this was to avoid problems where, for example, one thread was enumerating the contents of the segment while another thread was enqueueing and dequeueing. When there were multiple segments in the queue, accessing Count ended up being treated as an observation, but that meant that simply accessing the ConcurrentQueue‘s Count would render all of the multiple segments in the queue dead for further enqueues. The theory at the time was that such a trade-off was fine, because no one should be accessing the Count of the queue frequently enough for this to matter. That theory was wrong, and several customers reported significant slowdowns in their workloads because they were accessing the Count on every enqueue or dequeue. While the right solution is in general to avoid doing that, we wanted to fix this, and as it turns out, the fix was relatively straightforward, such that we could have our performance cake and eat it, too. The results are very obvious in the following benchmark.

private ConcurrentQueue<int> _cq;

[GlobalSetup]
public void Setup()
{
    _cq = new ConcurrentQueue<int>();
    for (int i = 0; i < 100; i++)
    {
        _cq.Enqueue(i);
    }
}

[Benchmark]
public void EnqueueCountDequeue()
{
    _cq.Enqueue(42);
    _ = _cq.Count;
    _cq.TryDequeue(out _);
}

ImmutableDictionary<TKey, TValue> also got some attention. A customer reported that they’d compared ImmutableDictionary<TKey, TValue> and Dictionary<TKey, TValue> and found the former to be measurably slower for lookups. This is to be expected, as the types use very different data structures, with ImmutableDictionary optimized for being able to inexpensively create a copy of the dictionary with a mutation, something that’s quite expensive to do with Dictionary; the trade-off is that it ends up being slower for lookups. Still, it caused us to take a look at the costs involved in ImmutableDictionary lookups, and PR dotnet/corefx#35759 includes several tweaks to improve it, changing a recursive call to be non-recursive and inlinable and avoiding some unnecessary struct wrapping. While this doesn’t make ImmutableDictionary and Dictionary lookups equivalent, it does improve ImmutableDictionarymeasurably, especially when it contains just a few elements.

private ImmutableDictionary<int, int> _hundredInts;

[GlobalSetup]
public void Setup()
{
    _hundredInts = ImmutableDictionary.Create<int, int>();
    for (int i = 0; i < 100; i++)
    {
        _hundredInts = _hundredInts.Add(i, i);
    }
}

[Benchmark]
public int Lookup()
{
    int count = 0;
    {
        for (int i = 0; i < 100; i++)
        {
            for (int j = 0; j < 100; j++)
            {
                if (_hundredInts.TryGetValue(j, out _))
                {
                    count++;
                }
            }
        }
    }
    return count;
}

Another collection that’s seen measurable improvements in .NET Core 3.0 is BitArray. Lots of operations, including construction, were optimized in PR dotnet/corefx#33367.

private byte[] _bytes = Enumerable.Range(0, 100).Select(i => (byte)i).ToArray();

[Benchmark]
public BitArray BitArrayCtor() => new BitArray(_bytes);

Core operations like Set and Get were further improved in PR dotnet/corefx#35364 from @omariom by streamlining the relevant methods and making them inlineable

private BitArray _ba = new BitArray(Enumerable.Range(0, 1000).Select(i => i % 2 == 0).ToArray());

[Benchmark]
public void GetSet()
{
    BitArray ba = _ba;
    for (int i = 0; i < 1000; i++)
    {
        ba.Set(i, !ba.Get(i));
    }
}

while other operations like Or, And, and Xor were vectorized in PR dotnet/corefx#33781. This benchmark highlights some of the wins.

private BitArray _ba1 = new BitArray(Enumerable.Range(0, 1000).Select(i => i % 2 == 0).ToArray());
private BitArray _ba2 = new BitArray(Enumerable.Range(0, 1000).Select(i => i % 2 == 1).ToArray());

[Benchmark]
public void Xor() => _ba1.Xor(_ba2);

Another example: SortedSet<T>. PR dotnet/corefx#30921 from @acerbusace tweaks how GetViewBetween changes how counts of the overall set and subset are managed, resulting in a nice performance boost.

private SortedSet<int> _set = new SortedSet<int>(Enumerable.Range(0, 1000));

[Benchmark]
public int EnumerateViewBetween()
{
    int count = 0;
    foreach (int item in _set.GetViewBetween(100, 200)) count++;
    return count;
}

Comparers have also seen some nice improvements in .NET Core 3.0. For example, PR dotnet/coreclr#21604 overhauled how comparers for enums are implemented in the runtime, borrowing the approach used in CoreRT. It’s often the case that performance optimizations involve adding code; this is one of those fortuitous cases where the better approach is not only faster, it’s also simpler and smaller.

private enum ExampleEnum : byte { A, B }

[Benchmark]
public void CompareEnums()
{
    var comparer = Comparer<ExampleEnum>.Default;
    for (int i = 0; i < 100_000_000; i++)
    {
        comparer.Compare(ExampleEnum.A, ExampleEnum.B);
    }
}

Networking

From the Kestrel web server running on System.Net.Sockets and System.Net.Security to applications accessing web services via HttpClient, System.Net now more than ever is critical path for many applications. It received a lot of attention in .NET Core 2.1, and continues to in .NET Core 3.0.

Let’s start with HttpClient. One improvement made in PR dotnet/corefx#32820 was around how buffering is handled, and in particular better respecting larger buffer size requests made as part of copying the response data when a content length was provided by the server. On a fast connection and with a large response body (such as the 10MB in this example), this can make a sizeable difference in throughput due to reduced syscalls to transfer data.

private HttpClient _client = new HttpClient();
private Socket _listener;
private Uri _uri;

[GlobalSetup]
public void Setup()
{
    _listener = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp);
    _listener.Bind(new IPEndPoint(IPAddress.Loopback, 0));
    _listener.Listen(int.MaxValue);
    var ep = (IPEndPoint)_listener.LocalEndPoint;
    _uri = new Uri($"http://{ep.Address}:{ep.Port}");

    Task.Run(async () =>
    {
        while (true)
        {
            Socket s = await _listener.AcceptAsync();
            var ignored = Task.Run(async () =>
            {
                ReadOnlyMemory<byte> headers = Encoding.ASCII.GetBytes("HTTP/1.1 200 OKrnContent-Length: 10485760rnrn");
                ReadOnlyMemory<byte> data = new byte[10*1024*1024]; // 10485760

                using (var serverStream = new NetworkStream(s, true))
                using (var reader = new StreamReader(serverStream))
                {
                    while (true)
                    {
                        while (!string.IsNullOrEmpty(await reader.ReadLineAsync())) ;
                        await s.SendAsync(headers, SocketFlags.None);
                        await s.SendAsync(data, SocketFlags.None);
                    }
                }
            });
        }
    });
}

[Benchmark]
public async Task HttpDownload()
{
    using (HttpResponseMessage r = await _client.GetAsync(_uri, HttpCompletionOption.ResponseHeadersRead))
    using (Stream s = await r.Content.ReadAsStreamAsync())
    {
        await s.CopyToAsync(Stream.Null);
    }
}

Now consider SslStream. Previous releases saw work done to make reads and writes on SslStream much more efficient, but additional work was done in .NET Core 3.0 as part of PRs dotnet/corefx#35091 and dotnet/corefx#35209 (and dotnet/corefx#35367 on Unix) to make initiating the connection more efficient, in particular in terms of allocations.

private NetworkStream _client;
private NetworkStream _server;

private static X509Certificate2 s_cert = GetServerCertificate();

private static X509Certificate2 GetServerCertificate()
{
    var certCollection = new X509Certificate2Collection();
    byte[] testCertBytes = Convert.FromBase64String(@"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");
    certCollection.Import(testCertBytes, "testcertificate", X509KeyStorageFlags.DefaultKeySet);
    return certCollection.Cast<X509Certificate2>().First(c => c.HasPrivateKey);
}

[GlobalSetup]
public void Setup()
{
    using (var listener = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp))
    {
        listener.Bind(new IPEndPoint(IPAddress.Loopback, 0));
        listener.Listen(1);

        var client = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp);
        client.Connect(listener.LocalEndPoint);
        Socket server = listener.Accept();

        _client = new NetworkStream(client);
        _server = new NetworkStream(server);
    }
}

[Benchmark]
public void SslConnect()
{
    using (var sslClient = new SslStream(_client, true, delegate { return true; }))
    using (var sslServer = new SslStream(_server, true, delegate { return true; }))
    {
        Task t = sslServer.AuthenticateAsServerAsync(s_cert, false, SslProtocols.None, false);
        sslClient.AuthenticateAsClient("localhost", null, SslProtocols.None, false);
        t.Wait();
    }
}

In System.Net.Sockets there’s another example of taking advantage of the IThreadPoolWorkItem interface discussed earlier. On Windows for asynchronous operations, we utilize “overlapped I/O”, utilizing threads from the I/O thread pool to execute continuations from socket operations; Windows queues I/O completion packets that these I/O pool threads then process, including invoking the continuations. On Unix, however, the mechanism is very different. There’s no concept of “overlapped I/O” on Unix, and instead asynchrony in System.Net.Sockets is achieved by using epoll (or kqueues on macOS), with all of the sockets in the system registered with an epoll file descriptor, and then one thread monitoring that epoll for changes. Any time an asynchronous operation completes for a socket, the epoll is signaled and the thread blocking on it wakes up to process it. If that thread were to run the socket continuation action then and there, it would end up potentially running unbounded work that could stall every other socket’s handling indefinitely, and in the extreme case, deadlock. Instead, this thread queues a work item back to the thread pool and then immediately goes back to processing any other socket work. Prior to .NET Core 3.0, that queueing involved an allocation, which meant that every asynchronously completing socket operation on Unix involved at least one allocation. As of PR dotnet/corefx#32919, that number drops to zero, as a cached object already being used (and reused) to represent asynchronous operations was changed to also implement IThreadPoolWorkItem and be queueable directly to the thread pool.

Other areas of System.Net have benefited from the efforts already alluded to previously, as well. For example, Dns.GetHostName used to use StringBuilder in its marshaling, but as of PR dotnet/corefx#29594 it no longer does.

[Benchmark]
public string GetHostName() => Dns.GetHostName();

And IPAddress.HostToNetworkOrder/NetworkToHostOrder have benefiting indirectly from the intrinsics push that was mentioned previously. In .NET Core 2.1, BinaryPrimitives.ReverseEndianness was added with an optimized software implementation, and these IPAddress methods were rewritten as simple wrappers for ReverseEndianness. Now in .NET Core 3.0, PR dotnet/coreclr#18398 turned ReverseEndianness into a JIT intrinsic for which the JIT can emit a very efficient BSWAP instruction, with the resulting throughput improvements accruing to IPAddress as well.

private long _value = 1234567890123456789;

[Benchmark]
public long HostToNetworkOrder() => IPAddress.HostToNetworkOrder(_value);

System.IO

Often going hand in hand with networking is compression, which has also seen some improvements in .NET Core 3.0. Most notably is that a key dependency was updated. On Unix, System.IO.Compression just uses the zlib library available on the machine, as it’s a standard part of most any distro/version. On Windows, however, zlib is generally nowhere to be found, and so it’s built and shipped as part of .NET Core on Windows. Rather than shipping the standard zlib, .NET Core includes a version modified by Intel with additional performance improvements not yet merged upstream. In .NET Core 3.0, we’ve sync’d to the latest available version of ZLib-Intel, version 1.2.11. This brings some very measurable performance improvements, in particular around decompression.

There have also been compression-related improvements that take advantage of previous improvements elsewhere in .NET Core. For example, the synchronous Stream.CopyTo was originally non-virtual, but as gains were found by overriding the asynchronous CopyToAsync and specializing its implementation for particular concrete stream types, CopyTo was made virtual to enjoy similar improvements. PR dotnet/corefx#29751 capitalized on this to override CopyTo on DeflateStream, employing similar optimizations in the synchronous implementation as were employed in the asynchronous implementation, essentially entailing minimizing the interop costs with zlib.

private byte[] _compressed;

[GlobalSetup]
public void Setup()
{
    var ms = new MemoryStream();
    using (var ds = new DeflateStream(ms, CompressionLevel.Fastest))
    {
        ds.Write(Enumerable.Range(0, 1_000_000).Select(i => (byte)i).ToArray(), 0, 1_000_000);
    }
    _compressed = ms.ToArray();
}

[Benchmark]
public void DeflateDecompress()
{
    using (var ds = new DeflateStream(new MemoryStream(_compressed), CompressionMode.Decompress))
    {
        ds.CopyTo(Stream.Null);
    }
}

Improvements were also made to BrotliStream (which as of .NET Core 3.0 is also used by HttpClient to automatically decompress Brotli-encoded content). Previously every new BrotliStream would also allocate a large buffer, but as of PR dotnet/corefx#35492, that buffer is pooled, as it is with DeflateStream (additionally, BrotliStream now as of PR dotnet/corefx#30135 overrides ReadByte and WriteByte to avoid allocations in the base implementation).

[Benchmark]
public void BrotliWrite()
{
    using (var bs = new BrotliStream(Stream.Null, CompressionLevel.Fastest))
    {
        for (int i = 0; i < 1_000; i++)
        {
            bs.WriteByte((byte)i);
        }
    }
}

Moving on from compression, it’s worth highlighting that formatting applies in more situations than just formatting individual primitives. TextWriter, for example, has multiple methods for writing with format strings, e.g. public override void Write(string format, object arg0, arg1). PR dotnet/coreclr#19235 improved on that for StreamWriter by providing specialized overrides that take a more efficient path that reduces allocation:

private StreamWriter _writer = new StreamWriter(Stream.Null);

[Benchmark]
public void StreamWriterFormat() => _writer.Write("Writing out a value: {0}", 42);

As another example, PR dotnet/coreclr#22102 from @TomerWeisberg improved the parsing performance of various primitive types on BinaryReader by special-casing the common situation where the BinaryReaderwraps a MemoryStream.

Or consider PR dotnet/corefx#30667 from @MarcoRossignoli, who added overrides to StringWriter for the Write{Line}{Async} methods that take a StringBuilder argument. StringWriter is just a wrapper around a StringBuilder, and StringBuilder knows how to append another StringBuilder to it, so these overrides on StringWriter can feed them right through.

private StringBuilder _underlying;
private StringWriter _writer;
private StringBuilder _sb;

[GlobalSetup]
public void Setup()
{
    _underlying = new StringBuilder();
    _writer = new StringWriter(_underlying);
    _sb = new StringBuilder("This is a test. This is only a test.");
}

[Benchmark]
public void Write()
{
    _underlying.Clear();
    _writer.Write(_sb);
}

System.IO.Pipelines is another IO-related library that’s received a lot of attention in .NET Core 3.0. Pipelines was introduced in .NET Core 2.1, and provides buffer-management as part of an I/O pipeline, used heavily by ASP.NET Core. A variety of PRs have gone into improving its performance. For example, PR dotnet/corefx#35171special-cases the common and default case where the Pool specified to be used by a Pipe is the default MemoryPool<byte>.Shared. Rather than go through MemoryPool<byte>.Shared in this case, the Pipe now bypasses it and goes to the underlying ArrayPool<byte>.Shared directly, which removes a layer of indirection but also the allocation of IMemoryOwner<byte> objects returned from MemoryPool<byte>.Rent. (Note that for this benchmark, since System.IO.Pipelines is part of a NuGet package rather than in the shared framework, I’ve added a Benchmark.NET config that specifies what package version to use with each run in order to show the improvements.)

// Run with: dotnet run -c Release -f netcoreapp2.1 --filter *Program*

private sealed class Config : ManualConfig // also add [Config(typeof(Config))] to the Program class
{
    public Config()
    {
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp21).WithNuGet("System.IO.Pipelines", "4.5.0").WithId("4.5.0"));
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp30).WithNuGet("System.IO.Pipelines", "4.6.0-preview5.19224.8").WithId("4.6.0-preview5.19224.8"));
    }
}

private readonly Pipe _pipe = new Pipe();
private byte[] _buffer = new byte[1024];

[Benchmark]
public async Task ReadWrite()
{
    var reader = _pipe.Reader;
    var writer = _pipe.Writer;

    for (int i = 0; i < 1000; i++)
    {
        ValueTask<ReadResult> vt = reader.ReadAsync();
        await writer.WriteAsync(_buffer);
        ReadResult rr = await vt;
        reader.AdvanceTo(rr.Buffer.End);
    }
}

PR dotnet/corefx#33658 from @benaadams allows Pipe to use the UnsafeQueueUserWorkItemboxing-related optimizations described earlier, PR dotnet/corefx#33755 avoids queueing unnecessary work items, PR dotnet/corefx#35939 tweaks the defaults used to better handle buffering in common cases, PR dotnet/corefx#35216 reduces the amount of slicing performed in various pipe operations, PR dotnet/corefx#35234 from @benaadams reduces the locking used in core operations, PR dotnet/corefx#35509 reduces argument validation (decreasing branching costs), PR dotnet/corefx#33000 focused on reducing costs associated with ReadOnlySequence<byte> that’s the main exchange type pipelines passes around, and PR dotnet/corefx#29837 further optimizes operations like GetSpan and Advance on the Pipe. The net result is to whittle away at already low CPU and allocation overheads.

// Run with: dotnet run -c Release -f netcoreapp2.1 --filter *Program*

private sealed class Config : ManualConfig // also add [Config(typeof(Config))] to the Program class
{
    public Config()
    {
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp21).WithNuGet("System.IO.Pipelines", "4.5.0").WithId("4.5.0"));
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp30).WithNuGet("System.IO.Pipelines", "4.6.0-preview5.19224.8").WithId("4.6.0-preview5.19224.8"));
    }
}

private readonly Pipe _pipe1 = new Pipe();
private readonly Pipe _pipe2 = new Pipe();
private byte[] _buffer = new byte[1024];

[GlobalSetup]
public void Setup()
{
    Task.Run(async () =>
    {
        var reader = _pipe2.Reader;
        var writer = _pipe1.Writer;
        while (true)
        {
            ReadResult rr = await reader.ReadAsync();
            foreach (ReadOnlyMemory<byte> mem in rr.Buffer)
            {
                await writer.WriteAsync(mem);
            }
            reader.AdvanceTo(rr.Buffer.End);
        }
    });
}

[Benchmark]
public async Task ReadWrite()
{
    var reader = _pipe1.Reader;
    var writer = _pipe2.Writer;

    for (int i = 0; i < 1000; i++)
    {
        await writer.WriteAsync(_buffer);
        long count = 0;
        while (count < _buffer.Length)
        {
            ReadResult rr = await reader.ReadAsync();
            count += rr.Buffer.Length;
            reader.AdvanceTo(rr.Buffer.End);
        }
    }
}

System.Console

Console isn’t something one normally thinks of as being performance-sensitive. However, there are two changes in this release that I think are worth calling attention to here.

First, there is one area of Console about which we’ve heard numerous concerns related to performance, where the performance impact visibly impacts users. In particular, interactive console applications generally do a lot of manipulation of the cursor, which also entails asking where the cursor currently is. On Windows, both the setting and getting of the cursor are relatively fast operations, with P/Invoke calls made to functions exported from kernel32.dll. On Unix, things are more complicated. There’s no standard POSIX function for getting or setting a terminal’s cursor position. Instead, there’s a standard convention for interacting with the terminal via ANSI escape sequences. To set the cursor position, one writes a sequence of characters to stdout (e.g. “ESC [ 12 ; 34 H” to indicate 12th row, 34th column) and the terminal interprets that and reacts accordingly. Getting the cursor position is more of an ordeal. To get the current cursor position, an application writes to stdout a request (e.g. “ESC [ 6 n”), and in response the terminal writes back to the application’s stdin a response something like “ESC [ 12 ; 34 R”, to indicate the cursor is at the 12th row and 34th column. That response then needs to be read from stdin and parsed. So, in contrast to a fast interop call on Windows, on Unix we need to write, read, and parse text, and do so in a way that doesn’t cause problems with a user sitting at a keyboard using the app concurrently… not particularly cheap. When just getting the cursor position now and then, it’s not a big deal. But when getting it frequently, and when porting code originally written for Windows where the operation was so cheap the code being ported may not have been very frugal with how often it asked for the position (asking for it more than is really needed), this has resulted in visible performance problems. Thankfully, the issue has been addressed in .NET Core 3.0, by PR dotnet/corefx#36049 from @tmds. The change caches the current position and then manually handles updating that cached value based on user interactions, such as handling typing or resizing the terminal window. (Note that Benchmark.NET operates in a way that redirects standard input and output for the process running the test, and that makes Console.CursorLeft/Top return 0 immediately, so for this test, I’ve just done a simple console app with a Stopwatch, which is, as you’ll see, more than sufficient given the discrepancy between costs in versions.)

using System;
using System.Diagnostics;

public class Program
{
    static void Main()
    {
        var sw = new Stopwatch();
        for (int iter = 0; iter < 5; iter++)
        {
            sw.Restart();
            for (int i = 0; i < 1_000; i++) { _ = Console.CursorLeft; }
            sw.Stop();
            Console.WriteLine(sw.Elapsed.TotalSeconds);
        }
    }
}

~/BlogPostBenchmarks$ dotnet run -c Release -f netcoreapp2.1
18.2152636
17.9935087
18.2676408
17.7891821
17.4141348
~/BlogPostBenchmarks$ dotnet run -c Release -f netcoreapp3.0
0.0648111
0.0001539
0.00013979999999999998
0.00013529999999999998
0.0001459

Another place where Console has been improved affects both Windows and Unix. Interestingly, this change was made for functional reasons (in particular for when running on Windows), but it has performance benefits as well for all OSes. In .NET, most of the times we specify buffer sizes it’s for performance reasons and represents a trade-off: the smaller the buffer size, the less memory is used but the more times operations may need to be performed to fill that buffer, and conversely the larger the buffer size, the more memory is used but the fewer times the buffer will need to be filled. It’s rare that the buffer size has a functional impact, but it actually can in Console. On Windows to read from the console, one calls either the ReadFile or ReadConsole functions, both of which accept a buffer to store the read data into. By default on Windows, reading from the console will not return until a newline, but Windows also needs somewhere to store the typed data, and it does so into the supplied buffer. Thus, Windows won’t let the user type more characters than can fit into the buffer, which means the line length a user can type is limited by the buffer size. For whatever historical reason, .NET has used a buffer size of 256 characters, limiting the typeable line length to that amount. PR dotnet/corefx#36212 expands that to 4096 characters, which much better matches other programming environments and allows for a much more reasonable line length. However, as is the case when increasing buffer sizes, relevant throughput involving that buffer improves as well, in particular when reading from files piped to stdin. For example, reading 8K of input data from stdin previously would have required 32 calls to ReadFile; with a 4K buffer, only 2 calls are required. The impact of that can be seen in this benchmark. (Again, this is harder to test with Benchmark.NET, so I’ve again just used a simple console app.)

using System;
using System.Diagnostics;
using System.IO;

public class Program
{
    static void Main()
    {
        //using (var writer = new StreamWriter(@"tmp.dat"))
        //{
        //    for (int i = 0; i < 10_000_000; i++)
        //    {
        //        writer.WriteLine("This is a test.  This is only a test.");
        //    }
        //}

        var sw = Stopwatch.StartNew();
        while (Console.ReadLine() != null) ;
        Console.WriteLine(sw.Elapsed.TotalSeconds);
    }
}

c:BlogPostBenchmarks>dotnet run -c Release -f netcoreapp2.1 < c:BlogPostBenchmarksbinReleasenetcoreapp2.1tmp.dat
4.8151814

c:BlogPostBenchmarks>dotnet run -c Release -f netcoreapp3.0 < c:BlogPostBenchmarksbinReleasenetcoreapp2.1tmp.dat
1.3161175999999999

System.Diagnostics.Process

There have been various functional improvements to the Process class in .NET Core 3.0, in particular on Unix, but there are a couple of performance-focused improvements I want to call out.

PR dotnet/corefx#31236 is another nice example of introducing a new performance-focused API and, at the same time, using it within .NET Core to further improve the performance of core libraries. In this case, it’s a low-level API on MemoryMarshal that enables efficiently reading structs from spans, something that’s done in spades as part of the interop in System.Diagnostics.Process. I like that example, not because it makes for a massive performance improvement, but because it highlights the general pattern I like to see: adding new APIs for others to consume and in the same breath using those APIs to better the technology itself.

A more impactful example, though, comes from @joshudson in PR dotnet/corefx#33289, which changed the native code used to fork a new process from using the fork function to instead using the vfork function. The benefit of vfork is that it avoids copying the page tables of the parent process into the child process, with the assumption that the child process is then just going to overwrite everything anyway via an almost immediate exec call. fork does copy-on-write, but if the process is modifying a lot of state concurrently (e.g. with the garbage collector running), this can get expensive quickly and unnecessarily. For this benchmark, I’ve just written a nop C program in a test.c file:

int main() { return 0; }

and compiled it with GCC:

gcc -o test test.c

to give us a target for Process.Start to invoke.

[Benchmark]
public void ProcessStartWait() => Process.Start("/home/stephentoub/BlogPostBenchmarks/test").WaitForExit();

LINQ

Previous releases have seen a ton of investment in optimizing LINQ. There’s less of that in .NET Core 3.0, as a lot of the common patterns have already been covered well. However, there are still some nice improvements to be found in the release.

It’s relatively rare that new operators are added to System.Linq itself, as the very nature of extension methods makes it easy for anyone to build up and share their own library of extension methods they consider to be useful (and several well-established such libraries exist). Even so, .NET Core 2.0 saw a new TakeLast method added. In .NET Core 3.0, PR dotnet/corefx#36051 by @Romasz updated TakeLast to integrate with the internal IPartition<T> interface that enables several operators to cooperate, helping to optimize (in some situations quite heavily) various uses of the operator.

private IEnumerable<int> _enumerable = new int[1000].Select(i => i);

[Benchmark]
public int SumLast10() => _enumerable.TakeLast(10).Sum();

Just recently, PR dotnet/corefx#37410 optimized the relatively common pattern of using Enumerable.Range(...).Select(…), teaching Select about the object generated by Range and allowing for the enumeration performed by Select to skip going through IEnumerable<T> and instead just loop through the intended numerical range directly.

[Benchmark]
public int[] RangeSelectToArray() => Enumerable.Range(0, 100).Select(i => i * 2).ToArray();

Enumerable.Empty<T>() was also changed in PR dotnet/corefx#31025 to better compose with optimizations already elsewhere in .NET Core’s System.Linq implementation. While no one should be writing code that explicitly calls additional LINQ operators directly on the result of Enumerable.Empty<T>(), it is common to return the result of Empty<T>() as one possible return value from an IEnumerable<T>-returning method, and then for the caller to tack on additional operators, such that this optimization does actually have a meaningful effect.

[Benchmark]
public int[] EmptyTakeSelectToArray() => Enumerable.Empty<int>().Take(10).Select(i => i).ToArray();

Across .NET Core, we’re also paying more attention to assembly size, in particular as it can impact ahead-of-time (AOT) compilation. PRs like dotnet/corefx#35213, which employs “ThrowHelpers” in the heavily-generic LINQ, help to reduce generated code size, which has benefits in and of itself but can also help with other areas of performance.

Interop

Interop is another one of those areas that’s critically important both to customers of .NET as well as to .NET itself, as a lot of functionality in .NET is layered on top of underlying operating system functionality that requires interop to access. As such, performance improvements in interop itself end up impacting a wide array of components.

One notable improvement is in SafeHandle, and it’s another example of where moving code from native to managed helped improve performance. SafeHandle is the recommended way for managing the lifetime of native resources, whether represented by handles on Windows or by file descriptors on Unix, and it’s used in exactly that way internally in all of our managed libraries in coreclr and corefx. One of the reasons it’s the recommended solution is that it uses appropriate synchronization to ensure that these native resources aren’t closed from managed code while they’re still being used, and that means that the interop layer needs to track every time a P/Invoke call is made with a SafeHandle, invoking DangerousAddRef prior to the call, DangerousRelease after the call, and DangerousGetHandle to extract the actual pointer value to pass to the native function. In previous releases of .NET, the core pieces of those implementations were in the runtime, which meant managed code needed to make InternalCalls to native code in the runtime for each of those operations. In .NET Core 3.0 as of PR dotnet/coreclr#22564, those operations have been ported to managed code, removing the overhead associated with each of those transitions.

private SafeFileHandle _sfh = new SafeFileHandle((IntPtr)12345, ownsHandle: false);

[Benchmark]
public IntPtr SafeHandleOps()
{
    bool success = false;
    try
    {
        _sfh.DangerousAddRef(ref success);
        return _sfh.DangerousGetHandle();
    }
    finally
    {
        if (success)
        {
            _sfh.DangerousRelease();
        }
    }
}

There are also examples for improvements to marshaling. Earlier in this post, I highlighted a variety of cases where StringBuilder was used as part of marshaling and interop. For the record, I personally dislike StringBuilder being used in interop, as it adds cost and complexity for relatively little benefit, and as a result did work in PRs like dotnet/corefx#33780 and dotnet/coreclr#21120 to remove almost all use of StringBuilder marshaling in coreclr and corefx. However, there is still a lot of code built around StringBuilder, and it deserves to be as fast as possible. PR dotnet/coreclr#17928 avoids a bunch of unnecessary work and allocation that happens as part of StringBuilder marshaling, and leads to improvements like this:

private const int MAX_PATH = 260;
private StringBuilder _sb = new StringBuilder(MAX_PATH);

[DllImport("kernel32", CharSet = CharSet.Unicode, SetLastError = true)]
private static extern uint GetTempPathW(int bufferLen, [Out]StringBuilder buffer);

[Benchmark]
public void StringBuilderMarshal() => GetTempPathW(MAX_PATH, _sb);

And of course, specific uses of interop and marshaling have also improved. For example, FileSystemWatcher‘s interop on macOS had been using MarshalAs attributes, which forced the runtime to do additional marshaling work on every OS callback, including allocating arrays. PR dotnet/corefx#34715 moved FileSystemWatcher‘s interop to use a more efficient scheme that doesn’t entail additional allocations nor marshaling directives. Or consider dotnet/corefx#30099, where System.Drawing was switched to using a much more efficient scheme of marshaling and interop, with a managed array being pinned and passed directly to native code instead of allocating additional memory and copying to it.

// Run with: dotnet run -c Release -f netcoreapp2.1 --filter *Program*

private sealed class Config : ManualConfig // also add [Config(typeof(Config))] to the Program class
{
    public Config()
    {
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp21).WithNuGet("System.Drawing.Common", "4.5.1").WithId("4.5.1"));
        Add(Job.MediumRun.With(CsProjCoreToolchain.NetCoreApp30).WithNuGet("System.Drawing.Common", "4.6.0-preview5.19224.8").WithId("4.6.0-preview5.19224.8"));
    }
}

private Bitmap _image;
private Graphics _graphics;
private Point[] _points;

[GlobalSetup]
public void Setup()
{
    _image = new Bitmap(100, 100);
    _graphics = Graphics.FromImage(_image);
    _points = new[]
    {
        new Point(10, 10), new Point(20, 1), new Point(35, 5), new Point(50, 10),
        new Point(60, 15), new Point(65, 25), new Point(50, 30)
    };
}

[Benchmark]
public void TransformPoints()
{
    _graphics.TransformPoints(CoordinateSpace.World, CoordinateSpace.Page, _points);
    _graphics.TransformPoints(CoordinateSpace.Device, CoordinateSpace.World, _points);
    _graphics.TransformPoints(CoordinateSpace.Page, CoordinateSpace.Device, _points);
}

Peanut butter

In previous sections of this post, I highlighted groups of PRs that addressed various areas of .NET in an impactful way, where some piece of mainstream functionality was significantly improved. But those aren’t the only areas or kinds of PRs that matter.

In .NET we also have what we sometimes refer to as “peanut butter”. We have a ton of code that’s generally great for most applications but that has a myriad of small opportunities for improvements. Those improvements alone don’t make anything better, but they fix a smearing of performance penalties across a large swath of code, and the more of such issues we can fix, the better performance becomes overall. An allocation removed here, some unnecessary cycles eliminated there, some unnecessary code removed there. Here are just a sampling of PRs that went in to address such “peanut butter”:

• Lower bounds explicitly provided to Array.Copy. Calling Array.Copy(src, dst, length) requires the runtime to call GetLowerBound on each of the src and the dst arrays. When working with T[]s, the lower bound is 0, and we can just explicitly pass in 0 for both bounds and avoid the implicit GetLowerBound calls. PR dotnet/coreclr#21756 does that in a variety of places.
• Cheaper copying to new arrays. In a variety of places, a List<T> stored some data, a new array was then allocated based on the length of the list, and the contents then copied to the array with CopyTo. PR dotnet/coreclr#22101 from @benaadams recognized the silliness of this and replaced that pattern with simply using List<T>.ToArray.
• Nullable<T>.Value vs GetValueOrDefault. Nullable<T> has two main members to access the value: Value and GetValueOrDefault. It’s initially counter-intuitive, but GetValueOrDefault is actually cheaper: Value needs to check whether the instance has a value or not, throwing if it doesn’t, whereas GetValueOrDefault just always returns the value field, and it’ll be default if there was no value. PR dotnet/coreclr#22297 fixed up a variety of call sites where GetValueOrDefault could be used instead.
• Array.Empty<T>(). In previous releases, lots of zero-length array allocations were changed to instead use Array.Empty<T>(), both in libraries and via compiler changes for things like params arrays. That trend continues in .NET Core 3.0, with PR dotnet/corefx#30235 doing another sweep through corefx and replacing even more zero-length allocations with the cached Array.Empty<T>().
• Avoiding lots of little allocations all over the place. For new code being written, we’re very cost-conscious and keep an eye out for allocations that, even if small and rare, could be easily replaced by something less expensive. For existing code, the most impactful allocations show up in profiling of key scenarios and are squashed whenever possible. But there are a lot of small allocations here and there that generally don’t pop up on our radar until we have another reason to review and profile the relevant code. In every release, we end up removing a bunch of these. For example, all of these PRs contributed to reducing the allocation peanut butter across coreclr and corefx in .NET Core 3.0:
  • In System.Collections: dotnet/corefx#30528
  • In System.Data: dotnet/corefx#30130
  • In System.Data.SqlClient: dotnet/corefx#34044, dotnet/corefx#34047, dotnet/corefx#34234,  dotnet/corefx#34999, dotnet/corefx#35549, dotnet/corefx#34048, dotnet/corefx#34390, and dotnet/corefx#34393, all from @Wraith2
  • In System.Diagnostics: dotnet/coreclr#21752
  • In System.IO: dotnet/corefx#30509, dotnet/corefx#30514, dotnet/coreclr#21760, dotnet/corefx#37546
  • In System.Globalization: dotnet/coreclr#18546, dotnet/coreclr#21121
  • In System.Net: dotnet/corefx#30521, dotnet/corefx#30530, dotnet/corefx#30508, dotnet/corefx#30529, dotnet/corefx#34356, dotnet/corefx#36021
  • In System.Reflection: dotnet/coreclr#21770, dotnet/coreclr#21758
  • In System.Security: dotnet/corefx#30512, dotnet/corefx#29612
  • In System.Uri: dotnet/corefx#33641, dotnet/corefx#36056
  • In System.Xml: dotnet/corefx#34196
• Avoiding explicit static cctors. Any type that has static fields initialized ends up with a static constructor (cctor) to run that initialization. But depending on how the initialization is authored can impact performance. In particular, if the developer explicitly writes a static cctor rather than initializing the fields as part of the static field declarations, the C# compiler will not mark the type as beforefieldinit. Having the type marked beforefieldinit can be beneficial for performance, because it allows the runtime more flexibility in when it performs the initialization, which in turn allows the JIT more flexibility about how it can optimize, and whether locking might be needed when accessing static methods on the type. PRs like dotnet/coreclr#21718 and dotnet/coreclr#21715 from @benaadams have removed such static cctors that can layer in small costs across a wide swath of accessing code.
• Using a cheaper, sufficient equivalent. IndexOf on strings and spans returns the position of a found element, whereas Contains just returns whether the element was found. The latter can be slightly more efficient, because it doesn’t need to track the exact location of an element, just that it existed. Even so, lots of call sites that could have used Contains instead used IndexOf. PRs dotnet/coreclr#19874 and dotnet/corefx#32249 by @grant-d addressed that. Another example, SocketsHttpHandler(the default HttpMessageHandler behind HttpClient) was using DateTime.UtcNow when determining whether a connection could be reused for the next request or not, but Environment.TickCount is cheaper and has sufficient resolution and accuracy for this purpose, so PR dotnet/corefx#35401 switched it to use that. Another example, PR dotnet/corefx#37548 tweaks the overloads of Array.Copy used in a bunch of places to avoid unnecessary GetLowerBound() calls to lookup the lower bound for arrays we know have a lower bound of 0.
• Simplifying interop. The interop infrastructure in .NET is quite powerful and comprehensive, with lots of knobs that allow for specifying how calls should be made and how data should be transformed. However, many come with a cost, such as needing the runtime to generate a marshaling stub to perform the various required transformations. PRs dotnet/corefx#36544 and dotnet/corefx#36071, for example, tweaked interop signatures to avoid overheads associated with such marshaling code.
• Avoiding unnecessary globalization. Due to how various System.String APIs were designed almost two decades ago, it can be easy to accidentally employ culture-aware string comparisons when it’s not intended. Such comparisons can be functionally incorrect for a given task and also more costly, involving more expensive calls to the operating system or globalization library. In particular, String.IndexOf with a char argument uses ordinal comparison, but String.IndexOf with a string argument (even if it’s a single character) uses the current culture to perform the comparison. PRs dotnet/corefx#37499 addresses a bunch of such cases in System.Net, an area in which one almost always wants to do ordinal comparisons, generally the case when doing parsing for text-based protocols.
• Avoiding unnecessary ExecutionContext flow. ExecutionContext is the primary vehicle for ambient state “flowing” through a program and across asynchronous calls, in particular AsyncLocal<T>. In order to achieve such flow, code that spawns an async operation (e.g. Task.Run, Timer, etc.) or code that creates a continuation to run when some other operation finishes (e.g. await) needs to “capture” the current ExecutionContext, hang on to it, and then later when executing the relevant work, use that captured ExecutionContext‘s Run method to do so. If the work being performed doesn’t actually require the ExecutionContext, we can avoid flowing it to avoid the small associated overhead. PRs dotnet/corefx#37551, dotnet/corefx#33235, and dotnet/corefx#33080 are examples: they switch several uses of CancellationToken.Registerover to the new CancellationToken.UnsafeRegister method, the only difference compared to Register being that it doesn’t flow ExecutionContext. As another example, PR dotnet/coreclr#18670 changed CancellationTokenSource so that when it creates a Timer, it doesn’t unnecessarily capture ExecutionContext. Or consider PR dotnet/coreclr#20294, which ensures that any such captured ExecutionContext is dropped as soon as it’s not needed from completed Tasks.
• Centralized / optimized bit operations. PR dotnet/coreclr#22118 from @benaadams introduced a BitOperations class that serves to centralize a bunch of bit-twiddling operations (rotating, leading zero count, population count, log, etc.). This type was later augmented and enhanced in PRs from @grant-d like dotnet/coreclr#22497, dotnet/coreclr#22584, and dotnet/coreclr#22630, which also serve to use these shared helpers from everywhere across System.Private.Corelib where such bit-twiddling operations are required. This ensures that all such call sites (of which there are currently ~70) get the best implementation the runtime can muster, whether that be an implementation that takes advantage of the current hardware’s instruction set or one that utilizes a software fallback.

GC

No blog post on performance would be complete without discussing the garbage collector. Many of the improvements cited thus far have involved reducing allocations, which is in part about reducing direct costs but more so about reducing the load placed on the garbage collector and minimizing the work it needs to do. But improving the GC itself is also a key focus, and one that’s gotten attention in this release, as it has in previous releases.

PR dotnet/coreclr#21523 includes a variety of performance improvements, from improvements to locking to better free list management. PR dotnet/coreclr#23251 from @mjsabby adds support to the GC for Large Pages (“Huge Pages” on Linux), which can be opted-into by very large applications that experience bottlenecks due to the translation lookaside buffer (TLB). And PR dotnet/coreclr#22003 further optimized the write barriers employed by the GC.

One notable piece of work is improving behavior on machines with a large number of processors, e.g. PR dotnet/coreclr#23824. Rather than trying to explain it here, I’ll simply refer to @Maoni0’s blog post on the subject: https://blogs.msdn.microsoft.com/maoni/2019/04/03/making-cpu-configuration-better-for-gc-on-machines-with-64-cpus/.

Similarly, a lot of work has gone into the release to improve the behavior and performance of the GC when operating in a containerized environment (and in particular in one that’s heavily constrained), such as in PR dotnet/coreclr#22180. Again, @Maoni0 can do a much better job than I can describing this work, and you can read all about it her two blog posts, running-with-server-gc-in-a-small-container-scenario-part-0 and running-with-server-gc-in-a-small-container-scenario-part-1-hard-limit-for-the-gc-heap.

JIT

A lot of goodness has gone into the just-in-time (JIT) compiler in .NET Core 3.0.

One of the most impactful changes is tiered compilation (this is split across many PRs, but for example PR dotnet/coreclr#23599). Tiered compilation is a solution for the problem that very good compilation from MSIL to native code takes time; the more analysis to be done, the more optimizations to be applied, the longer it takes. But with a JIT compiler that does that code generation at runtime, that time comes at the direct expense of application start-up, and so you’re left with a trade-off: do you spend more time generating better code but take longer to get going, or do you spend less time generating less-good code but get going faster? Tiered compilation is a scheme for accomplishing both. The idea is that methods are first compiled with a fast pass that applies few-to-no optimizations but that completes very quickly, and then as methods are seen to execute again and again, those methods are re-JIT’d, this time with more time spent on code quality.

Interestingly, though, tiered compilation isn’t just about start-up time. There are optimizations that the re-compilation can take advantage of that weren’t available the first time around. For example, tiered compilation can apply to ready-to-run (R2R) images, a form of precompilation employed by assemblies in the .NET Core shared framework. These assemblies contain precompiled native code, but in some ways the optimizations that can be applied during that native code generation are limited in order to aid in version resiliency, e.g. cross-module inlining doesn’t happen with R2R. So, the R2R code can help enable faster start-up, but then methods found to be used frequently can be re-compiled via tiered compilation, thereby taking advantage of such optimizations the original precompiled code was restricted from using.

Here’s an example of that. First, we can run the following benchmark.

private XmlDocument _doc = new XmlDocument();

[Benchmark]
public void LoadXml()
{
    _doc.RemoveAll();
    _doc.LoadXml("<Root><Element attrib="foo" attrib2="foo2">foo</Element><Element attrib="foo" attrib2="foo2">foo</Element><Element attrib="foo" attrib2="foo2">foo</Element><Element attrib="foo" attrib2="foo2">foo</Element><Element attrib="foo" attrib2="foo2">foo</Element><Element attrib="foo" attrib2="foo2">foo</Element><Element attrib="foo" attrib2="foo2">foo</Element><Element attrib="foo" attrib2="foo2">foo</Element></Root>");
}

Then, we can run it again, but this time with tiered compilation disabled by setting the COMPlus_TieredCompilationenvironment variable to 0.

There are a variety of environment variables that configure tiered compilation and in what situations it’s enabled. For more details, see https://github.com/dotnet/coreclr/issues/24064.

Another really cool improvement in the JIT comes in PR dotnet/coreclr#20886. In previous releases of .NET, the JIT could optimize the usage of some primitive type static readonly fields as if they were constants. For example, if a static readonly int field were initialized to the value 42 by the time some code that used that field was JIT compiled, the JIT compiler would effectively treat that field instead as a const, and do constant folding and all other forms of optimizations that would otherwise apply. In .NET Core 3.0, the JIT can now utilize the type of static readonlyfields to do additional optimizations. For example, if a static readonly field is typed as a base type but is then set to a derived type, the JIT might be able to see the actual type of the object stored in the field, and then when a virtual method is called on it, devirtualize the call and even potentially inline it.

private static readonly Base s_base;

static Program() => s_base = new Derived();

[Benchmark]
public void AccessStatic() => s_base.Method();

private sealed class Derived : Base { public override void Method() { } }
private abstract class Base { public abstract void Method(); }

That highlights some improvements that have gone into devirtualization, but there are others, such as in PRs dotnet/coreclr#20447, dotnet/coreclr#20292, and dotnet/coreclr#20640 which, when combined with PRs like dotnet/coreclr#20637 from @benaadams, help with APIs like ArrayPool<T>.Shared.

[Benchmark]
public void RentReturn() => ArrayPool<byte>.Shared.Return(ArrayPool<byte>.Shared.Rent(256));

Another nice improvement is around zeroing of locals. Even when the initlocals flag isn’t set (as of PR dotnet/corefx#34406, it’s cleared for all assemblies in coreclr and corefx), the JIT still needs to zero out references in locals so that the GC doesn’t see and misinterpret garbage, and that zero’ing can take a measurable amount of time, in particular in methods that do a lot of work with spans. PRs dotnet/coreclr#23498 and dotnet/coreclr#13868 make some nice improvements in this area.

private byte[] _bytes = new byte[1];

[Benchmark]
public void StackZero()
{
    Span<byte> a, b;
    a = _bytes;
    b = _bytes;
    Nop(a, b);
}

[MethodImpl(MethodImplOptions.NoInlining)]
private void Nop(Span<byte> a, Span<byte> b) { }

Another example relates to structs. As more and more recognition has come to .NET performance, in particular around allocation, there’s been a significant increase in the use of value types, often wrapping one another. For example, awaiting a ValueTask<T> results in calling GetAwaiter() on that value task, and that returns a ValueTaskAwaiter<T> that wraps the ValueTask<T>. PR dotnet/coreclr#19429 improves the situation by removing unnecessary copies involved in these operations.

[Benchmark]
public int WrapUnwrap() => ValueTuple.Create(ValueTuple.Create(ValueTuple.Create(42))).Item1.Item1.Item1;

What’s Next?

As I write this post, I count 29 pending performance-focused PRs in the coreclr repo and another 8  in the corefx repo. Some of those are likely to be merged in time for the .NET Core 3.0 release, as will, I’m sure, additional PRs that haven’t even been opened yet. In short, even after all of the improvements detailed in for .NET Core 2.0, .NET Core 2.1, and now in this post for .NET Core 3.0, and even with all of those improvements contributing to ASP.NET Core being one of the fastest web servers on the planet, there is still incredible opportunity for performance to keep getting better and better, and for you to help achieve that. Hopefully this post has made you excited about the potential .NET Core 3.0 holds. I look forward to reviewing your PRs as we all contribute to this exciting future together!

The post Performance Improvements in .NET Core 3.0 appeared first on .NET Blog.

Inclusivity is a priority for building a modern workplace at Rogers Communications, a leading Canadian media company. From office renovations to Microsoft 365 business software with built-in assistive technologies, employees are empowered to achieve their best for the company and its customers.

The post Rogers builds a more inclusive culture that supports diverse team members, with help from Microsoft 365 appeared first on Microsoft 365 Blog.

Today marks Global Accessibility Awareness Day, one of the days we celebrate the progress made by our customers and partners to create more inclusive workplaces, as well as look ahead to what more we can do as a community to empower everyone in the workplace.

The post Building the inclusive workplace we imagine, together appeared first on Microsoft 365 Blog.

Conversational experiences have become the norm, whether you’re looking to track a package or to find out a store’s hours of operation. At Microsoft Build 2019, we highlighted a few customers who are building such conversational experiences using the Microsoft Bot Framework and Azure Bot Service to transform their customer experience.

• LaLiga built its own virtual assistant, which allows fans to experience and interact with LaLiga across multiple platforms.
• BMW has created the BMW Intelligent Personal Assistant to deliver conversational experiences across multiple canvases.

As users become more familiar with bots and virtual assistants, they will invariably expect more from their conversational experiences. For this reason, Bot Framework SDK and tools are designed to help developers be more productive in building conversational AI solutions. Here are some of the key announcements we made at Build 2019:

Bot Framework SDK and tools

Adaptive dialogs

The Bot Framework SDK now supports adaptive dialogs (preview). Adaptive dialog dynamically updates conversation flow based on context and events. Developers can define actions, each of which can have a series of steps defined by the result of events happening in the conversation to dynamically adjust to context. This is especially handy when dealing with conversation context switches and interruptions in the middle of a conversation. Adaptive dialog combines input recognition, event handling, model of the conversation (dialog) and output generation into one cohesive, self-contained unit. The diagram below depicts how adaptive dialogs can allow a user to switch contexts. In this example, a user is looking to book a flight, but switches context by asking for weather related information which may influence travel plans.

You can read more about adaptive dialogs here.

Skills

Developers can compose conversational experiences by stitching together re-usable conversational capabilities, known as skills. Implemented as Bot Framework bots, skills include language models, dialogs, and cards that are reusable across applications. Current skills, available in preview, include Email, Calendar, and Points of Interest.

Within an enterprise using skills you can now integrate multiple sub-bots owned by different teams into a central bot, or more broadly leverage common capabilities provided by other developers. With the preview of skills, developers can create a new bot (from the Virtual Assistant template) and add/remove skills with one command line operation incorporating all dispatch and configuration changes. Get started with skill developer templates (.NET, TS).

Virtual assistant solution accelerator

The Enterprise Template is now the Virtual Assistant Template, allowing developers to build a virtual assistant with out of the box with skills, adaptive cards, typescript generator, updated conversational telemetry and PowerBI analytics, and ARM based automated Azure deployment. It also provides C# template simplified and aligned to ASP.NET MVC pattern with dependency injection. Developers who have already made use of the Enterprise Template and want to use the new capabilities can follow these steps to get started quickly.

Emulator

The Bot Framework Emulator has released a preview of the new Bot Inspector feature: a way to debug and test your Bot Framework SDK v4 bots on channels like Microsoft Teams, Slack, Cortana, Facebook Messenger, Skype, etc. As you have the conversation, messages will be mirrored to the Bot Framework Emulator where you can inspect the message data that the bot received. Additionally, a snapshot of the bot state for any given turn between the channel and the bot is rendered as well. You can inspect this data by clicking on the "Bot State" element in the conversation mirror. Read more about Bot Inspector.

Language generation (preview)

Streamlines the creation of smart and dynamic bot responses by constructing meaningful, variable, and grammatically correct responses that a bot can send back to the user. Visit the GitHub repo for more details.

QnA Maker

Easily handle multi-turn conversation

With QnA Maker, you can now handle a predefined set of multi-turn question and answer flows. For example, you can configure QnA Maker to help troubleshoot a product with a customer by preconfiguring a set of questions and follow up question prompts to lead users to specific answers. QnA Maker supports extraction of hierarchical QnA pairs from a URL, .pdf, or .docx files. Read more about QnA Maker multi-turn in our docs, check out the latest samples, and watch a short video.

Simplified deployment

We’ve simplified the process of deploying a bot. Using a pre-defined bot framework v4 template, you can create a bot from any published QnA Maker knowledge base. Not only can you now create a complex QnA Maker knowledge base in minutes, but you can now deploy it to supported channels like Teams, Skype, or Slack in minutes.

Language Understanding (LUIS)

Language Understanding has added several features that let developers extract more detailed information from text, so users can now build more intelligent solutions with less effort.

Roles for any entity type

We have extended roles to all entity types, which allows the same entities to be classified with different subtypes based on context.

New visual analytics dashboard

There’s now a more detailed, visually-rich, comprehensive analytics dashboard. It's user-friendly design highlights common issues most users face when designing applications by providing simple explanations on how to resolve them to help users gain more insight into their models’ quality, potential data problems, and guidance to adopt best practices.

Dynamic lists

Data is ever-changing and different from one end-user to another. Developers now have more granular control of what they can do with Language Understanding, including being able to identify and update models at runtime through dynamic lists and external entities. Dynamic lists are used to append to list entities at prediction time, permitting user-specific information to get matched exactly.

Read more about the new Language Understanding features, available through our new v3 API, in our docs. Customers like BMW, Accenture, Vodafone, and LaLiga are using Azure to build sophisticated bots faster and find new ways to connect with their customers.

Get started

With these enhancements, we are delivering value across the entire Microsoft Bot Framework SDKs and tools, Language Understanding, and QnA maker in order to help developers become more productive in building a variety of conversational experiences.

We look forward to seeing what conversational experiences you will build for your customers. Get started today!

Watch on-demand sessions at Microsoft Build 2019:

• How to use Conversational AI to scale your business.
• Your Brand, Your Assistant – How to build your own voice-first assistant.
• Build Live – BMW and Bot Framework Virtual Assistant solution accelerator.
• Create a truly conversational bot in minutes using QnA Maker.

We continue to expand the Azure Marketplace ecosystem. For this volume, 22 new offers successfully met the onboarding criteria and went live. See details of the new offers below:

Applications

Consulting services

Hello Friends!

Each year after Microsoft Build, we run a world-wide developer event to bring all the latest Microsoft 365 technology to you, in person.

Through the collaboration between the MVP (Most Valuable Professionals) and RD (Regional Directors) communities, Dev Collective, Windows, Office, Developer Tools, and the Insider Team, we’ve expanded the content this year to bring you even more developer awesomeness. More code. More demos. More useful knowledge.

You’ll enjoy an inside peek into some of tomorrow’s innovative dev tech, as well as practical information you can use today. Plus, you’ll gain valuable access to a peer network along with exposure to all-star devs from a wide range of tech disciplines.

Imagine new ways to build Microsoft 365 user experiences when the Insider Dev Tour comes to you this year. Just starting out? No worries, the tour is curated for everyone—from hobbyists to students to experts alike.

Agenda varies by location, but you can expect to find developer demo-focused practical sessions with topics such as:

• Introduction to Microsoft Graph Services
• Web Development with NodeJS and Microsoft Developer Tools
• Embedded and IoT Solutions with Microsoft Windows IoT Core
• Command Line / Terminal and Windows Subsystem for Linux
• Coding your Future with the Windows Insider Program
• Desktop Apps with the Microsoft Graph
• UWP User Interfaces with the latest APIS and OSS libraries
• Developing with the New Edge Browser
• Desktop Apps with .NET Core
• AI Platform / Machine Learning on Windows
• Progressive Web Apps with the New Edge
• NET Core 3.0
• Build apps for Microsoft Teams with Microsoft Graph and Web Technology

The day will start, of course, with a great keynote that covers the best from Microsoft Build.

We’re rolling out locations over the next week. You may not see your city on the site on day 1, but they’re all coming. Here’s a list of some of the countries we’re running events in this year, in partnerships with the local communities:

If your local city is not yet open for registration, be sure to check back next week and register!

Whether you’re interested in Microsoft Windows, Teams, Graph, Identity or IoT, the Insider Dev Tour has you covered. Interested in developing with the latest dev tools like VS Code, the Windows Subsystem for Linux, and Visual Studio? Yes. We have that. Web dev? We made sure you’re covered with content on JavaScript, Node, ASP.Net, and tools.

Find your local event and register now!

Thank you, and see you there!

Pete & Dona (@pete_brown, @donasarkar)

#InsiderDevTour

The post Announcing the Insider Dev Tour 2019! appeared first on Windows Developer Blog.

When it comes to developers’ documentation, it is essential that we capture their interest and lead them down the path of success as soon as possible. Across multiple languages, developer ecosystems have been providing their communities with interactive documentation where users can read the docs, run code and, edit it all in one place.
For the past two years, the language team has been evolving Try.NET to support interactive documentation both online and offline.

What is Try.NET

Try .NET is an interactive documentation generator for .NET Core.

Try .NET Online

When Try .NET initially launched in September 2017, on docs.microsoft.com, we executed all our code server side using Azure Container Instances. However, over the past fives months we switched our code execution client side using Blazor and Web Assembly.

You can see this for yourself by visiting this page, and going to the developer tools. Under the Console tab, you will see the following message WASM:Initialized now, switch over to the Network tab, you will see all the DLLs now running on the client side.

Console Tab: WASM Initialized

Network tab: DLLs

Try .NET Offline

It was essential for us to provide interactive documentation both online and offline. For our offline experience, it was crucial for us to create an experience that plugged into our content writers’ current workflow.
In our findings, we noticed that our content developers had two common areas they consistently used while creating developer documentation.

1. A sample project that users could download and run.
2. Markdown files with a set of instructions, and code snippets they copied and pasted from their code base.

Try .NET enables .NET developers to create interactive markdown files with the use of the dotnet try global tool.
To make your markdown files interactive, you will need the .NET Core SDK, the dotnet try global tool, Visual Studio / VS Code, and your repo.

How are we doing this?

Extending Markdown

In markdown, you use fenced code blocks to highlight code snippets. You triple back-ticks before and after code blocks. You can add optional language identifiers to enable syntax highlighting in your fenced code block.

For example, C# code block would look like this:

``` cs
var name ="Rain";
Console.WriteLine($"Hello {name.ToUpper()}!");
```

With Try .NET we have extended our code fences to include additional options.

``` cs --region methods --source-file .myappProgram.cs --project .myappmyapp.csproj
var name ="Rain";
Console.WriteLine($"Hello {name.ToUpper()}!");
```

We have created the following options:

• --region option points to a C# region
• --source-file option points to the program file
• -- project option that points to project files plus the references to system assemblies.

So, what we are doing here is accessing code from a #region named methods in a backing project myapp and enabling you to run it within your markdown.

Using #regions

In our markdown we extended the code fence to include --region option that points to a C# region which targets a region named methods.

So, your Program.cs would look like this:

using System;

    namespace HelloWorld
    {
        class Program
        {
            static void Main(string[] args)
            {
                #region methods
                var name ="Rain"
                Console.WriteLine($"Hello{name.ToUpper()}!");
                #endregion
            }
        }
    }

dotnet try verify

dotnet try verify is a compiler for your documentation. With this command, you can make sure that every code snippet will work and is in sync with the backing project.

The goal of dotnet try verify is to validate that your documentation works as intended.

By running dotnet try verify you will be able to detect markdown and compile errors. For example, if I removed a semicolon from the code snippet above and renamed the region from methods to method, I would get the following errors.

Try the dotnet try global tool

dotnet try is now available for use! This is an early preview of the dotnet try global tool so, please check our repository and NuGet package for regular updates.

Getting Started

• Clone this repo
• Checkout out the samples branch git checkout samples
• Install .NET Core SDK 3.0 and 2.1 currently dotnet try global tool targets 2.1.
• Go to your terminal
• Install the Try .NET tools

dotnet tool install --global dotnet-try --version 1.0.19264.11

Updating to the latest version of the tool is easy just run the command below

dotnet tool update -g dotnet-try

• Navigate to the Samples directory of this repository and, type the following dotnet try.

• This will launch the browser.


Try .NET is now Open Source

Try .NET source code is now on GitHub!  As we are still in the early stages of our development, we are unable to take any feature PRs at the moment but, we do intend to do this in the future. Please feel free to file any bugs reports under our issues. And if you have any feature suggestion, please submit them under our issues using the community suggestions label.

Looking forward to seeing all the interactive .NET documentation, and workshop you create.

The post Create Interactive .NET Documentation with Try .NET appeared first on .NET Blog.

Today we’re happy to announce the availability of our release candidate (RC) of TypeScript 3.5. Our hope is to collect feedback and early issues to ensure our final release is simple to pick up and use right away.

To get started using the RC, you can get it through NuGet, or use npm with the following command:

npm install -g typescript@rc

You can also get editor support by

• Downloading for Visual Studio 2019/2017
• Following directions for Visual Studio Code and Sublime Text.

Let’s explore what’s new in 3.5!

• Speed improvements
• The Omit helper type
• Improved excess property checks in union types
• The --allowUmdGlobalAccess flag
• Smarter union type checking
• Higher order type inference from generic constructors
• Breaking changes

Speed improvements

TypeScript 3.5 introduces several optimizations around type-checking and incremental builds.

Type-checking speed-ups

Much of the expressivity of our type system comes with a cost – any more work that we expect the compiler to do translates to longer compile times. Unfortunately, as part of a bug fix in TypeScript 3.4 we accidentally introduced a regression that could lead to an explosion in how much work the type-checker did, and in turn, type-checking time. The most-impacted set of users were those using the styled-components library. This regression was serious not just because it led to much higher build times for TypeScript code, but because editor operations for both TypeScript and JavaScript users became unbearably slow.

Over this past release, we focused heavily on optimizing certain code paths and stripping down certain functionality to the point where TypeScript 3.5 is actually faster than TypeScript 3.3 for many incremental checks. Not only have compile times fallen compared to 3.4, but code completion and any other editor operations should be much snappier too.

If you haven’t upgraded to TypeScript 3.4 due to these regressions, we would value your feedback to see whether TypeScript 3.5 addresses your performance concerns!

--incremental improvements

TypeScript 3.4 introduced a new --incremental compiler option. This option saves a bunch of information to a .tsbuildinfo file that can be used to speed up subsequent calls to tsc.

TypeScript 3.5 includes several optimizations to caching how the state of the world was calculated – compiler settings, why files were looked up, where files were found, etc. In scenarios involving hundreds of projects using TypeScript’s project references in --build mode, we’ve found that the amount of time rebuilding can be reduced by as much as 68% compared to TypeScript 3.4!

For more details, you can see the pull requests to

• cache module resolution
• cache settings calculated from tsconfig.json

The Omit helper type

Much of the time, we want to create an object that omits certain properties. It turns out that we can express types like that using TypeScript’s built-in Pick and Exclude helpers. For example, if we wanted to define a Person that has no location property, we could write the following:

type Person = {
    name: string;
    age: number;
    location: string;
};

type RemainingKeys = Exclude<keyof Person, "location">;

type QuantumPerson = Pick<Person, RemainingKeys>;

// equivalent to
type QuantumPerson = {
    name: string;
    age: number;
};

Here we “subtracted” "location" from the set of properties of Person using the Exclude helper type. We then picked them right off of Person using the Pick helper type.

It turns out this type of operation comes up frequently enough that users will write a helper type to do exactly this:

type Omit<T, K extends keyof any> = Pick<T, Exclude<keyof T, K>>;

Instead of making everyone define their own version of Omit, TypeScript 3.5 will include its own in lib.d.ts which can be used anywhere. The compiler itself will use this Omit type to express types created through object rest destructuring declarations on generics.

For more details, see the pull request on GitHub to add Omit, as well as the change to use Omit for object rest.

Improved excess property checks in union types

TypeScript has a feature called excess property checking in object literals. This feature is meant to detect typos for when a type isn’t expecting a specific property.

type Style = {
    alignment: string,
    color?: string
};

const s: Style = {
    alignment: "center",
    colour: "grey"
//  ^^^^^^ error!
};

In TypeScript 3.4 and earlier, certain excess properties were allowed in situations where they really shouldn’t have been. For instance, TypeScript 3.4 permitted the incorrect name property in the object literal even though its types don’t match between Point and Label.

type Point = {
    x: number;
    y: number;
};

type Label = {
    name: string;
};

const thing: Point | Label = {
    x: 0,
    y: 0,
    name: true // uh-oh!
};

Previously, a non-disciminated union wouldn’t have any excess property checking done on its members, and as a result, the incorrectly typed name property slipped by.

In TypeScript 3.5, the type-checker at least verifies that all the provided properties belong to some union member and have the appropriate type, meaning that the sample above correctly issues an error.

Note that partial overlap is still permitted as long as the property types are valid.

const pl: Point | Label = {
    x: 0,
    y: 0,
    name: "origin" // okay
};

The --allowUmdGlobalAccess flag

In TypeScript 3.5, you can now reference UMD global declarations like

export as namespace foo;

from anywhere – even modules – using the new --allowUmdGlobalAccess flag.

This feature might require some background if you’re not familiar with UMD globals in TypeScript. A while back, JavaScript libraries were often published as global variables with properties tacked on – you sort of hoped that nobody picked a library name that was identical to yours. Over time, authors of modern JavaScript libraries started publishing using module systems to prevent some of these issues. While module systems alleviated certain classes of issues, they did leave users who were used to using global variables out in the rain.

As a work-around, many libraries are authored in a way that define a global object if a module loader isn’t available at runtime. This is typically leveraged when users target a module format called “UMD”, and as such, TypeScript has a way to describe this pattern which we’ve called “UMD global namespaces”:

export as namespace preact;

Whenever you’re in a script file (a non-module file), you’ll be able to access one of these UMD globals.

So what’s the problem? Well, not all libraries conditionally set their global declarations. Some just always create a global in addition to registering with the module system. We decided to err on the more conservative side, and many of us felt that if a library could be imported, that was probably the the intent of the author.

In reality, we received a lot of feedback that users were writing modules where some libraries were consumed as globals, and others were consumed through imports. So in the interest of making those users’ lives easier, we’ve introduced the allowUmdGlobalAccess flag in TypeScript 3.5.

For more details, see the pull request on GitHub.

Smarter union type checking

When checking against union types, TypeScript typically compares each constituent type in isolation. For example, take the following code:

type S = { done: boolean, value: number }
type T =
    | { done: false, value: number }
    | { done: true, value: number };

declare let source: S;
declare let target: T;

target = source;

Assigning source to target involves checking whether the type of source is assignable to target. That in turn means that TypeScript needs to check whether S:

{ done: boolean, value: number }

is assignable to T:

{ done: false, value: number } | { done: true, value: number }

Prior to TypeScript 3.5, the check in this specific example would fail, because S isn’t assignable to { done: false, value: number } nor { done: true, value: number }. Why? Because the done property in S isn’t specific enough – it’s booleanwhereas each constituent of T has a done property that’s specifically true or false. That’s what we meant by each constituent type being checked in isolation: TypeScript doesn’t just union each property together and see if S is assignable to that. If it did, some bad code could get through like the following:

interface Foo {
    kind: "foo";
    value: string;
}

interface Bar {
    kind: "bar";
    value: number;
}

function doSomething(x: Foo | Bar) {
    if (x.kind === "foo") {
        x.value.toLowerCase();
    }
}

// uh-oh - luckily TypeScript errors here!
doSomething({
    kind: "foo",
    value: 123,
});

So clearly this behavior is good for some set of cases. Was TypeScript being helpful in the original example though? Not really. If you figure out the precise type of any possible value of S, you can actually see that it matches the types in Texactly.

That’s why in TypeScript 3.5, when assigning to types with discriminant properties like in T, the language actually will go further and decompose types like S into a union of every possible inhabitant type. In this case, since boolean is a union of true and false, S will be viewed as a union of { done: false, value: number } and { done: true, value: number }.

For more details, you can see the original pull request on GitHub.

Higher order type inference from generic constructors

In TypeScript 3.4, we improved inference for when generic functions that return functions like so:

function compose<T, U, V>(
    f: (x: T) => U, g: (y: U) => V): (x: T) => V {

    return x => g(f(x))
}

took other generic functions as arguments, like so:

function arrayify<T>(x: T): T[] {
    return [x];
}

type Box<U> = { value: U }
function boxify<U>(y: U): Box<U> {
    return { value: y };
}

let newFn = compose(arrayify, boxify);

Instead of a relatively useless type like (x: {}) => Box<{}[]>, which older versions of the language would infer, TypeScript 3.4’s inference allows newFn to be generic. Its new type is <T>(x: T) => Box<T[]>.

TypeScript 3.5 generalizes this behavior to work on constructor functions as well.

class Box<T> {
    kind: "box";
    value: T;
    constructor(value: T) {
        this.value = value;
    }
}

class Bag<U> {
    kind: "bag";
    value: U;
    constructor(value: U) {
        this.value = value;
    }
}


function composeCtor<T, U, V>(
    F: new (x: T) => U, G: new (y: U) => V): (x: T) => V {

    return x => new G(new F(x))
}

let f = composeCtor(Box, Bag); // has type '<T>(x: T) => Bag<Box<T>>'
let a = f(1024); // has type 'Bag<Box<number>>'

In addition to compositional patterns like the above, this new inference on generic constructors means that functions that operate on class components in certain UI libraries like React can more correctly operate on generic class components.

type ComponentClass<P> = new (props: P) => Component<P>;
declare class Component<P> {
    props: P;
    constructor(props: P);
}

declare function myHoc<P>(C: ComponentClass<P>): ComponentClass<P>;

type NestedProps<T> = { foo: number, stuff: T };

declare class GenericComponent<T> extends Component<NestedProps<T>> {
}

// type is 'new <T>(props: NestedProps<T>) => Component<NestedProps<T>>'
const GenericComponent2 = myHoc(GenericComponent);

To learn more, check out the original pull request on GitHub.

Breaking changes

Generic type parameters are implicitly constrained to unknown

In TypeScript 3.5, generic type parameters without an explicit constraint are now implicitly constrained to unknown, whereas previously the implicit constraint of type parameters was the empty object type {}.

In practice, {} and unknown are pretty similar, but there are a few key differences:

• {} can be indexed with a string (k["foo"]), though this is an implicit any error under --noImplicitAny.
• {} is assumed to not be null or undefined, whereas unknown is possibly one of those values.
• {} is assignable to object, but unknown is not.

The decision to switch to unknown is rooted that it is more correct for unconstrained generics – there’s no telling how a generic type will be instantiated.

On the caller side, this typically means that assignment to object will fail, and methods on Object like toString, toLocaleString, valueOf, hasOwnProperty, isPrototypeOf, and propertyIsEnumerable will no longer be available.

function foo<T>(x: T): [T, string] {
    return [x, x.toString()]
    //           ~~~~~~~~ error! Property 'toString' does not exist on type 'T'.
}

As a workaround, you can add an explicit constraint of {} to a type parameter to get the old behavior.

//             vvvvvvvvvv
function foo<T extends {}>(x: T): [T, string] {
    return [x, x.toString()]
}

From the caller side, failed inferences for generic type arguments will result in unknown instead of {}.

function parse<T>(x: string): T {
    return JSON.parse(x);
}

// k has type 'unknown' - previously, it was '{}'.
const k = parse("...");

As a workaround, you can provide an explicit type argument:

// 'k' now has type '{}'
const k = parse<{}>("...");

{ [k: string]: unknown } is no longer a wildcard assignment target

The index signature { [s: string]: any } in TypeScript behaves specially: it’s a valid assignment target for any object type. This is a special rule, since types with index signatures don’t normally produce this behavior.

Since its introduction, the type unknown in an index signature behaved the same way:

let dict: { [s: string]: unknown };
// Was okay
dict = () => {};

In general this rule makes sense; the implied constraint of “all its properties are some subtype of unknown” is trivially true of any object type. However, in TypeScript 3.5, this special rule is removed for { [s: string]: unknown }.

This was a necessary change because of the change from {} to unknown when generic inference has no candidates. Consider this code:

declare function someFunc(): void;
declare function fn<T>(arg: { [k: string]: T }): void;
fn(someFunc);

In TypeScript 3.4, the following sequence occurred:

• No candidates were found for T
• T is selected to be {}
• someFunc isn’t assignable to arg because there are no special rules allowing arbitrary assignment to { [k: string]: {} }
• The call is correctly rejected

Due to changes around unconstrained type parameters falling back to unknown (see above), arg would have had the type { [k: string]: unknown }, which anything is assignable to, so the call would have incorrectly been allowed. That’s why TypeScript 3.5 removes the specialized assignability rule to permit assignment to { [k: string]: unknown }.

Note that fresh object literals are still exempt from this check.

const obj = { m: 10 };
// okay
const dict: { [s: string]: unknown } = obj;

Depending on the intended behavior of { [s: string]: unknown }, several alternatives are available:

• { [s: string]: any }
• { [s: string]: {} }
• object
• unknown
• any

We recommend sketching out your desired use cases and seeing which one is the best option for your particular use case.

Improved excess property checks in union types

As mentioned above, TypeScript 3.5 is stricter about excess property checks on constituents of union types.

We have not witnessed examples where this checking hasn’t caught legitimate issues, but in a pinch, any of the workarounds to disable excess property checking will apply:

• Add a type assertion onto the object (e.g. { myProp: SomeType } as ExpectedType)
• Add an index signature to the expected type to signal that unspecified properties are expected (e.g. interface ExpectedType { myProp: SomeType; [prop: string]: unknown })

Fixes to unsound writes to indexed access types

TypeScript allows you to represent the operation of accessing a property of an object via the name of that property:

type A = {
    s: string;
    n: number;
};

function read<K extends keyof A>(arg: A, key: K): A[K] {
    return arg[key];
}

const a: A = { s: "", n: 0 };
const x = read(a, "s"); // x: string

While commonly used for reading values from an object, you can also use this for writes:

function write<K extends keyof A>(arg: A, key: K, value: A[K]): void {
    arg[key] = value;
}

In TypeScript 3.4, the logic used to validate a write was much too permissive:

function write<K extends keyof A>(arg: A, key: K, value: A[K]): void {
    // ???
    arg[key] = "hello, world";
}
// Breaks the object by putting a string where a number should be
write(a, "n");

In TypeScript 3.5, this logic is fixed and the above sample correctly issues an error.

Most instances of this error represent potential errors in the relevant code. If you are convinced that you are not dealing with an error, you can use a type assertion instead.

lib.d.ts includes the Omit helper type

TypeScript 3.5 includes a new Omit helper type. As a result, any global declarations of Omit included in your project will result in the following error message:

Duplicate identifier 'Omit'.

Two workarounds may be used here:

1. Delete the duplicate declaration and use the one provided in lib.d.ts.
2. Export the existing declaration from a module file or a namespace to avoid a global collision. Existing usages can use an import or explicit reference to your project’s old Omit type.

Object.keys rejects primitives in ES5

In ECMAScript 5 environments, Object.keys throws an exception if passed any non-object argument:

// Throws if run in an ES5 runtime
Object.keys(10);

In ECMAScript 2015, Object.keys returns [] if its argument is a primitive:

// [] in ES6 runtime
Object.keys(10);

This is a potential source of error that wasn’t previously identified. In TypeScript 3.5, if target (or equivalently lib) is ES5, calls to Object.keys must pass a valid object.

In general, errors here represent possible exceptions in your application and should be treated as such. If you happen to know through other means that a value is an object, a type assertion is appropriate:

function fn(arg: object | number, isArgActuallyObject: boolean) {
    if (isArgActuallyObject) {
        const k = Object.keys(arg as object);
    }
}

Note that this change interacts with the change in generic inference from {} to unknown, because {} is a valid objectwhereas unknown isn’t:

declare function fn<T>(): T;

// Was okay in TypeScript 3.4, errors in 3.5 under --target ES5
Object.keys(fn());

What’s next?

The final release of TypeScript 3.5 should be coming out at the end of the month. We encourage you to give the RC a try so we can ensure TypeScript 3.5 provides the ideal coding experience.

Happy hacking!

• Daniel Rosenwasser and the TypeScript Team

The post Announcing TypeScript 3.5 RC appeared first on TypeScript.

Kubernetes is taking the app development world by storm. Earlier this month, we shared that the Azure Kubernetes Service (AKS) was the fastest growing compute service in Azure’s history. Customers like Siemens Healthineers, Finastra, Maersk, and Hafslund are realizing the benefits of using AKS to easily deploy, manage and scale applications without getting into the toil of maintaining infrastructures.  As the community and adoption grows, Kubernetes itself is evolving, adding more enterprise-friendly features and extending to more scenarios.  The release of production-level support for Windows Server containers is a true testament to the evolution.

Today, we’re excited to announce the preview of Windows Server containers in Azure Kubernetes Service (AKS) for versions 1.13.5 and 1.14.0.  With this, Windows Server containers can now be deployed and orchestrated in AKS enabling new paths to migrate and modernize Windows Server applications in Azure.

Our customers have applications running on Linux and on Windows.  The ability to manage Windows and the latest Linux containers side by side in the same Kubernetes cluster with the exact same APIs, tools and support is what you have been asking us to support, which opens an abundance of new scenarios. For example, you can now add Windows node pools to existing Virtual Network; or deploy a Linux container running a reverse proxy or Redis cache and an IIS application in a Windows container in the same Kubernetes cluster and even as part of the same application - all with consistent monitoring experience and deployment pipelines.

Running Windows Server containers in AKS (preview) also means you can keep taking advantage of many existing Azure services and features that are helping make Kubernetes application development and management much easier, such as:

• Manage the lifecycle of Linux and Windows containers easily through Azure Container Registry, which pre-stages all container base images. To reduce network latency or meet rigorous compliance needs, Container Registry can automatically geo-replicate the container images to the data center close to where your users are.
• Deliver applications faster on any OS with a standardized deployment pipeline. Azure DevOps integration with AKS helps automate validation, testing, canary and ultimately production easily in just a few steps.
• Gain insights into the performance and health of your Kubernetes cluster and workloads with a comprehensive monitoring experience using Azure Monitor.

Now is the time to get started with Windows Server containers in Azure Kubernetes Service (preview) and we look forward to your feedback on these new features and experiences! If you are new to Kubernetes, check out these short Kubernetes whiteboard videos with Brendan Burns, one of the co-founders of Kubernetes, so you can learn how it works for both Windows and Linux!

We would like to take the moment to thank every contributor and customer, without whom, today’s announcement would not be possible.  We are proud to be part of the broader and vibrant Kubernetes community.

The weekend’s nearly here, so it’s almost time to relax. Don’t tell your boss that I suggested it, but maybe you should knock off a little early and catch up on the DevOps news. Lucky for me, I’m not in the office next week: I’ll be at Techorama Belgium and GitHub Satellite. Be sure to stop by and say hi if you’re there, too!

Configuring Cypress in CI with Azure DevOps Pipelines
End-to-end web testing is always tricky, and the Cypress test automation framework aims to make that easier, providing direct access with JavaScript. Mario Cardinal shows how to integrate Cypress into your Azure Pipelines CI builds.

Converting Existing pipeline to YAML, how to avoid double builds
Most of the people that I talk to are moving their existing builds that were created with the visual designer over to YAML – it’s generally as easy as “export as YAML”. But you still want to keep the old build definition around for old branches; Gian Maria Ricci reminds you to avoid queueing double builds when you do.

Container DevOps: Beyond Build (Part 5) – Prometheus Operator
On the Azure DevOps team, we believe that we haven’t really shipped a feature until we are collecting data about how it operates and are able to monitor that feature in production. Colin Dembovsky takes the DevOps pipeline beyond builds and looks at how to integrate monitoring.

Azure DevOps Pipelines: Leveraging OWASP ZAP in the Release Pipeline
It’s critical to shift-left as much as possible into the pull request and continuous integration processes; that especially includes security. You want to scan your applications early to find problems as quickly as possible, not weeks after a deploy. Francis Lacroix shows you how to integrate the OWASP Zed Attack Proxy into a pipeline.

As always, if you’ve written an article about Azure DevOps or find some great content about DevOps on Azure then let me know! I’m @ethomson on Twitter.

The post Top Stories from the Microsoft DevOps Community – 2019.05.17 appeared first on Azure DevOps Blog.

Summary

In a previous article, I talked about how you can leverage the power of OData with your existing ASP.NET Core API to bring in more features to your API consumers.

But there are different ways you could enable OData on your existing API that are just as simple but offers more powerful features than overriding your existing routes and enabling dependency injection.

For instance, if you’ve tried to perform a count operation using our previous method you will notice it doesn’t really return or perform anything, the same thing goes with many other features that we will talk about extensively in future articles.

In this article, however, I’m going to show you how you can enable OData on your existing ASP.NET Core API using EDM.

What is EDM?

EDM is short for Entity Data Model, it plays the role of a mapper between whatever data source and format you have and the OData engine.

In other words, whether your source of data is SQL, Cosmos DB or just plain text files, and whether your format is XML, Json or raw text or any other type out there, What the entity data model does is to turn that raw data into entities that allow functionality like count, select, filter and expand to be performed seamlessly through your API.

Setting Things up

Let’s set our existing API up with OData using EDM.

First and foremost, add in Microsoft.AspNetCore.OData nuget package to your ASP.NET Core project.

Once the nuget package is installed, let’s setup the configuration to utilize that package.

In your Startup.cs file, in your ConfigureServices function, add in the following line:

services.AddOData();

Important Note: This will work with ASP.NET Core 2.1, if you are trying to set this up with ASP.NET Core 2.2, then you must add another line of code as follows:

services.AddMvcCore(action => action.EnableEndpointRouting = false);

OData doesn’t yet support .NET Core 3.0 – at the time of this article, .NET Core 3.0 is still in preview, OData support will extend to 3.0 once it’s production ready.

Once that part is done, let’s build a private method to do a handshake between your existing data models (Students in this case) and EDM, as follows:

private IEdmModel GetEdmModel()
    {
        var builder = new ODataConventionModelBuilder();
        builder.EntitySet<Student>("Students");
        return builder.GetEdmModel();
    }

The student model we are using here is the same model we used in our previous article, as a reminder here’s how the model looks like:

public class Student
    {
        public Guid Id { get; set; }
        public string Name { get; set; }
        public int Score { get; set; }
    }

Now that we have created our EDM method, now let’s do one last configuration change in the Configure method in our Startup.cs file as follows:

app.UseMvc(routeBuilder =>
    {
        routeBuilder.Select().Filter().OrderBy().Expand().Count().MaxTop(10);
        routeBuilder.MapODataServiceRoute("api", "api", GetEdmModel());
    });

Just like our last article, we enabled the functionality we needed such as select, filter and order by then we used the MapODataServiceRoute method to utilize our EDM method.

We used “api” instead of “odata” as our first and second parameters as a route name and a route prefix to continue to support our existing APIs endpoints, but there’s a catch to that.

Your contract in this case will change, if your API returns a list of students like this:

[
  {
    "id": "acc25b4f-c53d-4363-ad33-e0c860a83a1b",
    "name": "Hassan Habib",
    "score": 100
  },
  {
    "id": "d42daeb4-37d7-4a20-9e9b-7f7a60f27ff6",
    "name": "Cody Allen",
    "score": 90
  },
  {
    "id": "db246814-d34e-40e4-aa00-b9192cec447b",
    "name": "Sandeep Pal",
    "score": 120
  },
  {
    "id": "c4e9efc9-40b7-4a85-b000-ce9c076fcd57",
    "name": "David Pullara",
    "score": 50
  }
]

With the EDM method, your contract will change a bit, your response will have some helpful metadata that we are going to talk about, and it will look like this:

{
  "@odata.context": "https://localhost:44374/api/$metadata#Students",
  "value": [
    {
      "Id": "9cef40f6-db31-4d4c-997d-8b802156dd4c",
      "Name": "Hassan Habib",
      "Score": 100
    },
    {
      "Id": "282be5ea-231b-4a59-8250-1247695f16c3",
      "Name": "Cody Allen",
      "Score": 90
    },
    {
      "Id": "b3b06596-729b-4c6f-b337-7ad11b01371b",
      "Name": "Sandeep Pal",
      "Score": 120
    },
    {
      "Id": "084bd81e-b8a2-471d-8396-ace675f73688",
      "Name": "David Pullara",
      "Score": 50
    }
  ]
}

That extra metadata is going to help us perform more operations than the old method.

In that case if you have existing consumers for your API, I recommend introducing a new endpoint, version or informing them to change their contracts, otherwise this will be a breaking change.

The other option is to change your route name and route prefix parameters to say “odata” instead, which is the standard way to implement OData.

The last thing we need to do to make this work for us is removing the notations on top of your existing API controller class, in our case we will remove these two lines:

    [Route("api/[controller]")]
    [ApiController]

And don’t forget to add the enabling querying annotation on top of your API method:

[EnableQuery()]

Putting OData into Action

Once that’s done, now you can try to perform higher operations using OData like Count for instance, you can call your endpoint with /api/students?$count=true and you should get:

{
  "@odata.context": "https://localhost:44374/api/$metadata#Students",
  "@odata.count": 4,
  "value": [
    {
      "Id": "6a7e60b8-cea9-4132-aac7-be9995e8e048",
      "Name": "Hassan Habib",
      "Score": 100
    },
    {
      "Id": "d6661173-4370-4781-b016-a311b0e96f14",
      "Name": "Cody Allen",
      "Score": 90
    },
    {
      "Id": "caad33c3-d2bf-443e-8623-4a033ca77de2",
      "Name": "Sandeep Pal",
      "Score": 120
    },
    {
      "Id": "eee8bb79-df81-4cc8-b03f-a3887ecabb50",
      "Name": "David Pullara",
      "Score": 50
    }
  ]
}

As you can see here, you have a new property @odata.count that shows you the count of the items in your list.

Final Notes

Now that you’ve learned about the simplest way (8 lines of code) to create a handshake between ASP.NET Core, OData and EDM here’s few notes:

1. EDM doesn’t have any dependency on the Entity Framework, in fact the whole purpose of creating an EDM is to link whatever data you have in any format it may be to the OData engine and serialize the results through an API endpoint.
2. EDM can only be useful if you need some specific OData features such as count and nextlink and so many other features that we will explore in future articles.
3. There’s more to learn about EDM, I encourage you to check all about EDM in this extensive, comprehensive documentation.
4. OData is an open-source project, I encourage you as you benefit from it’s amazing features to contribute to the project, suggest new features and participate with documentation and your experiences to keep the community active and useful for everyone.
5. You can clone the project I built and try things out from this github repo.

The post Simplifying EDM with OData appeared first on OData.

Summary

We talked in a previous article about enabling OData in your existing ASP.NET Core API using EDM.

One of the biggest advantages of following that method is to be able to take advantage of functionality such as count to enable an on-demand function in almost every web application such as navigation.

In this article, we are going to talk about navigation from an abstract perspective as a plain API call, then leverage that power in a Blazor application to enable data navigation or pagination.

API Navigation

Clone and run the example project I built for OData with EDM and run the project then try the following API call:

api/students?$count=true

The response to that would be:

"@odata.context": "https://localhost:44374/api/$metadata#Students",
  "@odata.count": 4,
  "value": [
    {
      "Id": "1185ee49-4086-456d-8149-22ea5ea4a726",
      "Name": "Hassan Habib",
      "Score": 100
    },
    {
      "Id": "f1d796c0-9bd4-4522-854d-2f1b64693853",
      "Name": "Cody Allen",
      "Score": 90
    },
    {
      "Id": "696a26c3-90fc-4abf-818f-8d4c961cb9bd",
      "Name": "Sandeep Pal",
      "Score": 120
    },
    {
      "Id": "cd166253-37ed-4c2b-af87-8f74ea7658db",
      "Name": "David Pullara",
      "Score": 50
    }
  ]
}

As you can see the response contains the count of all the data that this API could provide, we are going to need that later for our pagination process.

Now let’s try to control the quantity of that data using $skip and $top functionality as follows:

api/students?$count=true&$skip=1&$top=1

The response to that would be:

{
  "@odata.context": "https://localhost:44374/api/$metadata#Students",
  "@odata.count": 4,
  "value": [
    {
      "Id": "57de16b8-a997-471f-badf-d7f9b3f6dd1f",
      "Name": "Hassan Habib",
      "Score": 100
    }
  ]
}

You will notice that we have full control over navigating through that data.

The skip functionality will allow us to move forward in our list, while the top functionality will enable us to control the amount of data returned with every API call.

however, and since the data isn’t returned in any enforced particular order, using skip and top do not necessarily guarantee returning the same results every time, try to make the call multiple times and see the results change every time.

Therefore, we have to enforce some form of order to assure the returned results are consistent, so we are going to use OrderBy functionality to maintain that order.

Now your API call should look something like this:

api/students/$count=true&$orderby=Name&$skip=1&$top=1

The response to that would be always:

{
  "@odata.context": "https://localhost:44374/api/$metadata#Students",
  "@odata.count": 4,
  "value": [
    {
      "Id": "f92afca4-76e4-4ef2-89c9-2a350861c954",
      "Name": "David Pullara",
      "Score": 50
    }
  ]
}

Now we have more consistent, reliable order of data.

But an API call with ordered data can only seem amazing to back-end engineers but not necessarily to end users, which means we need a powerful easy to use UI framework to help us put that kind of power into action and displaying it to the world.

Thanks to Daniel Roth and his amazing team we now have Blazor, a modern framework for building interactive client-side web UI using .NET and C#.

Integrating with Blazor

In order for you to start a Blazor project you need to have few prerequisites in place which are:

1. Install .NET Core 3.0 on your machine, you can find it here
2. In VS2019 go to option -> .NET Core -> Use Previews of the .NET Core SDK

Once that’s done, restart your Visual Studio and start a new project.

If you’re still having problems enabling .NET Core 3.0 on your machine, watch this tutorial.

Now you can start a new project with ASP.NET Core and Blazor (server-side), make sure you select ASP.NET Core 3.0 from the dropdown so you can find that type of project as follows:

Once the project is created, you will notice that Blazor comes with a pre-built web application samples such as counter and fetch data.

Let’s start by creating a new folder, call it Models, then let’s define the data models we need to create an integration between Blazor and OData API.

So what we need here is a student and an API response models.

We need the API response model because once we enabled OData with EDM the response became more than just a list of students, it returns more metadata that we are going to use for our pagination project shortly.

So your Student model will be just identical to the one we built in the API project:

using System;

namespace BlazorPagination.Models
{
    public class Student
    {
        public Guid Id { get; set; }
        public string Name { get; set; }
        public int Score { get; set; }
    }
}

But the API response model, let’s call it StudentsApiResponse will look as follows:

using Newtonsoft.Json;
using System.Collections.Generic;

namespace BlazorPagination.Models
{
    public class StudentsApiResponse
    {
        [JsonProperty("@odata.count")]
        public int Count { get; set; }

        [JsonProperty("value")]
        public List<Student> Students { get; set; }
    }
}

Now that we have built the models, let’s build a service class to call our API and serialize the incoming data into consumable strongly typed values, let’s call it StudentsService.cs.

And because we will need to do some JSON serialization then we need to install Newtonsoft.Json package to simplify the serialization process and the notations on our Models.

Once that’s installed,  we type the following code to perform an API integration:

using BlazorPagination.Models;
using Newtonsoft.Json;
using System.Net.Http;
using System.Threading.Tasks;

namespace BlazorPagination.Data
{
    public class StudentsService
    {
        public async Task<StudentsApiResponse> GetStudentsAsync(int skip = 0, int top = 0)
        {
            string baseUrl = "https://localhost:1985";
            using (HttpClient client = new HttpClient())
            {
                var response = await client.GetAsync($"{baseUrl}/api/students?$orderby=Name&$count=true&$skip={skip}&$top={top}");

                if (response.IsSuccessStatusCode)
                {
                    var jsonString = await response.Content.ReadAsStringAsync();
                    return JsonConvert.DeserializeObject<StudentsApiResponse>(jsonString);
                }

                return new StudentsApiResponse();
            }
        }
    }
}

Let’s explain what the code is doing exactly.

We created a method GetStudentsAsync that returns the StudentsApiResponse that we get from our API call, and the method has two parameters to control the navigation through the API leveraging OData functionality to skip forward and control the size of the data coming back.

We are using HttpClient to perform an API GET call, we are enforcing the order by name as we have explained above, passing in the value of top and skip through string interpolation.

Then we deserialized the JSON response into StudentApiResponse.

This method is the point of integration between our OData-enabled API and our Blazor application, everything else from here is mainly focused on the rendering of that data.

In the Pages folder, let’s create a new file, FetchStudents.razor to render our data.

FetchStudents.razor will contain some C# code, HTML and Razor code to handle the service calling, rendering and navigation process.

Let’s start with the C# code, we need to reference at the top of our razor page the route let’s call it /fetchstudents – we also need to reference the namespaces where our models live and where our services live.

Finally we need to inject StudentsService so we can call the GetStudentsAsync method in our razor page.

@page "/fetchstudents"
@using BlazorPagination.Data
@using BlazorPagination.Models
@inject StudentsService StudentsService

Then we need to build three functions to handle the navigation of our data, one to be called to initialize the rendering and first page of data, one for navigating forward and one for navigating backward.

Here’s the code for these functions:

@functions {
    List<Student> students;
    int skip = 0;
    int top = 1;
    int count = 0;

    protected override async Task OnInitAsync()
    {
        var response = await StudentsService.GetStudentsAsync(0, top);
        count = response.Count;
        students = response.Students;
    }

    async Task Next()
    {
        skip++;

        var response = await StudentsService.GetStudentsAsync(skip, top);
        students = response.Students;
    }

    async Task Previous()
    {
        skip--;

        var response = await StudentsService.GetStudentsAsync(skip, top);
        students = response.Students;
    }
}

You can think of students, skip, top and count as global variables that are shared across all components in this razor page.

Each one of these functions makes an asynchronous call to our StudentsService method to get new data based on skip and top values.

You’ll notice that we control the values returned by increasing and decreasing the values of skip variable, everything else stays the same.

We made the code redundant for the purpose of this demo, otherwise the call to StudentsService can be simplified.

That wraps all most of the C# code we need for this page.

Now comes the HTML & Razor parts as follows:

We need to have a view when our data is still loading, which is when students are still in null state.

@if (students == null)
{
    <p><em>Loading...</em></p>
}

Now we need to render a table of students as follows:

<table class="table">
        <thead>
            <tr>
                <th>ID</th>
                <th>Name</th>
                <th>Score</th>
            </tr>
        </thead>
        <tbody>
            @foreach (var student in students)
            {
                <tr>
                    <td>@student.Id</td>
                    <td>@student.Name</td>
                    <td>@student.Score</td>
                </tr>
            }
        </tbody>
    </table>

Lastly, comes the navigation part, we need a next button, previous button and a label to show the count and how many pages left as follows:

<label bind="nav">@count/@(skip + 1)</label>

    if (top + skip > 1)
    {
        <button onclick=@Previous> ← </button>
    }

    if (top + skip < count)
    {
        <button onclick=@Next> → </button>
    }

We are showing the total number of pages in addition to the skip value + 1 because it’s zero-based counter.

Then we show and hide Previous and Next buttons based on whether there are any more navigation data in any direction or not.
The full code for the FetchStudents.razor page should look like this:

@page "/fetchstudents"
@using BlazorPagination.Data
@using BlazorPagination.Models
@inject StudentsService StudentsService

<h1>Students</h1>

<p>This component demonstrates fetching data from a service.</p>

@if (students == null)
{
    <p><em>Loading...</em></p>
}
else
{
    <table class="table">
        <thead>
            <tr>
                <th>ID</th>
                <th>Name</th>
                <th>Score</th>
            </tr>
        </thead>
        <tbody>
            @foreach (var student in students)
            {
                <tr>
                    <td>@student.Id</td>
                    <td>@student.Name</td>
                    <td>@student.Score</td>
                </tr>
            }
        </tbody>
    </table>

    <label bind="nav">@count/@(skip + 1)</label>

    if (top + skip > 1)
    {
        <button onclick=@Previous> ← </button>
    }

    if (top + skip < count)
    {
        <button onclick=@Next> → </button>
    }
}

@functions {
    List<Student> students;
    int skip = 0;
    int top = 1;
    int count = 0;

    protected override async Task OnInitAsync()
    {
        var response = await StudentsService.GetStudentsAsync(0, top);
        count = response.Count;
        students = response.Students;
    }

    async Task Next()
    {
        skip++;

        var response = await StudentsService.GetStudentsAsync(skip, top);
        students = response.Students;
    }

    async Task Previous()
    {
        skip--;

        var response = await StudentsService.GetStudentsAsync(skip, top);
        students = response.Students;
    }
}

The next thing we need to do here is to register the StudentsService in the startup.cs file in the ConfigureService as a singleton as follows:

services.AddSingleton<StudentsService>();

The last thing we need to do here is to add a navigation option to our Blazor app, so we are going to modify NavMenu.razor file in the Shared folder and add another option for fetching students as follows:

<li class="nav-item px-3">
            <NavLink class="nav-link" href="fetchstudents">
                <span class="oi oi-list-rich" aria-hidden="true"></span> Fetch Students
            </NavLink>
        </li>

Now let’s run our projects, both the OData API project and Blazor project need to be running at the same time, you can easily configure your solution to do that by simple right-clicking on your solution file, go to properties,  under common Properties select Startup Project (it should be selected by default) then choose Multiple startup projects as shows in the following screenshot:

Now, let’s run the project, your navigation menu on the left, go to Fetch Students and start experiencing full navigation experience with Blazor and OData

Final Notes

1. Blazor and .NET Core 3.0 are still in preview stage at the time of this article, I encourage you to stay up to date with our blogs to learn more about the latest updates with these technologies.
2. This is the source code of the project we built, let us know if you have any issues running it.

Bundling multiple powerful technologies such as Blazor and OData with ASP.NET Core might save you a lot of time implementing functionality that is simply a boilerplate, a functionality that doesn’t necessarily make your application any different from any other.
Our mission at Microsoft is to empower you to achieve more, because re-implementing a feature like pagination every time you need to list some data seems like a time-consuming task, instead we build technologies and frameworks like these to make your life easier, and help you get to your end goal faster. and we will continue to build powerful technologies that makes building robust mobile, web and desktop applications even simpler. because we want every developer to turn their ideas into a reality as fast as possible, whether it’s infrastructure, web development, cloud or mobile.
I encourage you to keep up with us on the latest products we offer in the software development world, we still have a lot to offer and we invite everyone to come celebrate innovation and success in our open source projects and our communities.

The post Enabling Pagination in Blazor with OData appeared first on OData.

News and updates

Azure SQL Database Edge: Enabling intelligent data at the edge

At Microsoft Build 2019, we announced Azure SQL Database Edge, available in preview, to help address the requirements of data and analytics at the edge using the performant, highly available and secure SQL engine. Developers will now be able to adopt a consistent programming surface area to develop on a SQL database and run the same code on-premises, in the cloud, or at the edge.

Microsoft Azure portal May 2019 update

This month is packed with updates on the Azure portal, including enhancements to the user experience, resource configuration, management tools, and more. Sign in to the Azure portal now and see everything that’s new for yourself. Download the Azure mobile app to stay connected to your Azure resources anytime, anywhere.

A Cosmonaut’s guide to the latest Azure Cosmos DB announcements

At Microsoft Build 2019 we announced exciting new capabilities, including the introduction of real-time operational analytics using new built in support for Apache Spark and a new Jupyter notebook experience for all Azure Cosmos DB APIs. We believe these capabilities will help our customers easily build globally distributed apps at Cosmos scale. But there is even more! This blog lists additional enhancements to the developer experience, announced at Microsoft Build.

Azure Updates

Learn about important Azure product updates, roadmap, and announcements. Subscribe to notifications to stay informed.

Generally available

Premium files redefine limits for Azure Files

Azure Premium Files preview is now available to everyone! Premium files is a new performance tier that unlocks the next level of performance for fully managed file services in the cloud. Premium tier is optimized to deliver consistent performance for IO-intensive workloads that require high-throughput and low latency. Premium shares store data on the latest solid-state drives (SSDs) making it suitable for a wide variety of workloads like file services, databases, shared cache storage, home directories, content and collaboration repositories, persistent storage for containers, media and analytics, high variable and batch workloads, and many more.

Technical content

Azure Firewall and network virtual appliances

Network security solutions can be delivered as appliances on premises, as network virtual appliances (NVAs) that run in the cloud or as a cloud native offering (known as firewall-as-a-service). Customers often ask us how Azure Firewall is different from Network Virtual Appliances, whether it can coexist with these solutions, where it excels, what’s missing, and the total cost of ownership (TCO) benefits expected. We answer these questions in this blog post.

Operationalizing your PostgreSQL database health checks using SQL Notebooks

Most Postgres database administrators and community members would usually bookmark or save such articles so they can revisit them and reuse the queries shared in the article to run checks against their databases. The common challenge with this approach is, you end up with many saved archives, and searching through them when you need it is time consuming and less productive. A better way to operationalize your health check runbooks and database scripts is by creating SQL Notebooks in Azure Data Studio. This blog explains how to do that.

The Urlist — An application study in Serverless and Azure

The Urlist is an application that lets you create lists of URL's that you can share with others. Get it? A list of URL’s? The Urlist? Listen, naming things is hard and all the good domains are already taken. This project was born out of the author’s realization that I was ending my presentations with a slide full of links to additional resources. That’s crazy! What exactly is the audience supposed to do with that? Take a picture with their phone and then go back and manually type it all in later? What decade is this!?

How to Migrate Windows Server 2008 R2 FSMO roles to Windows Server 2019

With the "end of support" on the horizon for Windows Server 2008 R2 coming January 2020, folks are looking around for resources to help them check off some high ticket items from their "to do" list. While coming back from my last Microsoft Ignite The Tour stop, the author had some time to kill waiting for a connection. So he dusted off some of his Active Directory admin skills and document the quick and dirty process of upgrading your Active Directory from 2008 R2 over to the latest version of Windows Server 2019.

AI Search Algorithms Every Data Scientist Should Know

While in recent years, search and planning algorithms have taken a back seat to machine and deep learning methods, better understanding these algorithms can boost the performance of your models. Additionally as more powerful computational technologies such as quantum computing emerge it is very likely that search based AI will make a comeback. This TL;DR post outlines a few of the key search algorithms in AI, why they are important, what and what they are used for.

Azure shows

Next-level maps with ArcGIS for .NET

This week, James is joined by friend of the show & Microsoft MVP Morten Nielsen who introduces us to the world of advanced mapping with ArcGIS for .NET and Xamarin. Morten walks us through what ArcGIS is, how developers can build and use custom maps and data in mobile apps, and awesome 3D visualizations on maps.

Deep Dive: Deploying IoT Edge workloads on Kubernetes

Azure IoT Edge now features support for running natively on the Kubernetes orchestrator. This video goes into how the integration works and caps off with a demo showing what the experience is like for deploying a workload on an on-premise Kubernetes cluster.

Howden: How they built a knowledge-mining solution with Azure Search

Customers across industries including healthcare, legal, media, and manufacturing are looking for new solutions to solve business challenges with AI, including knowledge mining with Azure Search. Howden, a global engineering company, focuses on providing quality solutions for air and gas handling. With over a century of engineering experience, Howden creates industrial products that help multiple sectors improve their everyday processes; from mine ventilation and waste water treatment to heating and cooling. Watch a video to see how they implemented a knowledge-mining solution with Azure Search.

How to enable and use soft delete in a storage account | Azure Portal Series

In this video of the Azure Portal “how to” Series, you will learn how to enable and use “soft delete” in an Azure storage account.
